SRAM Rockshox SID SL - Charger 2 Damper Service Procedures; Charger 2 Damper Removal

39
Charger 2 Damper Service
Charger 2 Damper Service
200 Hour Service Charger 2 Damper Removal
RL: RL: Turn the lockout adjuster knob to the open, unlocked position. Turn the lockout adjuster knob to the open, unlocked position.
Remove the knob.Remove the knob.
RL R:RL R: Remove the cable stop collar. Remove the spool. Remove the cable stop collar. Remove the spool.
Remove the Charger 2 Damper assembly.Remove the Charger 2 Damper assembly.
Clean the upper tube threads.Clean the upper tube threads.
1
RL Unlocked RL: 2 mm
2
RL R: 2 mm RL R: 2 mm
3
RL: Top Cap/Cassette Tool RL R: 24 mm
