SRAM Rockshox SID SL - Charger 2 Damper Installation - Remote

48
Charger 2 Damper Installation - Remote
200 Hour Service Charger 2 Damper Installation - Remote
Install and tighten the Charger 2 Damper into the upper tube.Install and tighten the Charger 2 Damper into the upper tube.
Some damper top caps have a groove around the hex adjuster. Some damper top caps have a groove around the hex adjuster.
Damper top caps with a groove must be used with a spool that also Damper top caps with a groove must be used with a spool that also
has a groove. has a groove.
Proceed to the next step if your top cap and spool have a groove. Proceed to the next step if your top cap and spool have a groove.
Proceed toProceed to Step 4 i Step 4 if your top cap and spool do not have a groove.f your top cap and spool do not have a groove.
24 mm 28 N.m (250 in-lb)
1
2
Top Cap without Groove Spool without Groove
Top Cap with Groove Spool with Groove
Groove
Groove
