SRAM Rockshox SID SL - Page 40

40
Charger 2 Damper Removal
Remove top cap o-ring. Install a new o-ring on the top cap.Remove top cap o-ring. Install a new o-ring on the top cap.
Clamp the wrench flats of the Charger 2 Damper in a vise with the Clamp the wrench flats of the Charger 2 Damper in a vise with the
rebound shaft oriented upward. rebound shaft oriented upward.
Use the wrench flats and remove the rebound damper assembly. Wrap Use the wrench flats and remove the rebound damper assembly. Wrap
a shop towel around the cartridge tube to absorb oil. a shop towel around the cartridge tube to absorb oil.
Remove the cartridge tube from the vise and pour the oil into an Remove the cartridge tube from the vise and pour the oil into an
oil pan.oil pan.
Squeeze the bladder to drain the oil from the top cap assembly into an Squeeze the bladder to drain the oil from the top cap assembly into an
oil pan.oil pan.
4
5
SID SID SL
SID 19 mm SID SL 19 mm
6
7
