22
Lower Leg Seal Service
Hold the lower leg steady and use a mallet to seat the dust wiper Hold the lower leg steady and use a mallet to seat the dust wiper
seal into the lower leg until the seal surface is flush with the top of the seal into the lower leg until the seal surface is flush with the top of the
lower leg.lower leg.
Repeat on the other side.Repeat on the other side.
NOTICE
Only press the wiper seal into the lower leg until it is flush with the
top surface of the lower leg. Pressing the wiper seal below the top
surface of the lower leg will compress the foam rings.
Install the outer wire spring.Install the outer wire spring.
200 Hour Service Continue the 200 Hour Service with Air Spring Service .
7
8
