Damper Assembly
Thread the cartridge tube into the seal head hand tight.Thread the cartridge tube into the seal head hand tight.
Pull the damper shaft to full extension.Pull the damper shaft to full extension.
Clamp the Charger Damper RL cartridge tube into a vise with Charger Clamp the Charger Damper RL cartridge tube into a vise with Charger
vise blocks.vise blocks.
Thread a bottom bolt into the rebound damper shaft.Thread a bottom bolt into the rebound damper shaft.
Pour Maxima PLUSH 3wt suspension oil into the tube until it is almost Pour Maxima PLUSH 3wt suspension oil into the tube until it is almost
half full. Slowly cycle the rebound damper shaft in and out half way to half full. Slowly cycle the rebound damper shaft in and out half way to
remove air bubbles trapped under the rebound damper piston. Stop remove air bubbles trapped under the rebound damper piston. Stop
when no bubbles are visible in the oil.when no bubbles are visible in the oil.
3
4
Vise with Charger Vise Blocks
PLUSH 3wt
5
