61
Damper Installation
RL RRL R: Install the cable stop collar with the housing guide oriented : Install the cable stop collar with the housing guide oriented
outward within the 75 degree range in the diagram. outward within the 75 degree range in the diagram.
NOTICE
The cable stop collar and remote cable housing must clear the lower
leg arch when the fork is fully compressed.
Tighten the set screw.Tighten the set screw.
Install the remote spool onto the hex adjuster with the cable set screw Install the remote spool onto the hex adjuster with the cable set screw
oriented within the 20 degree range in the diagram. oriented within the 20 degree range in the diagram.
Install and tighten the remote spool retaining screw.Install and tighten the remote spool retaining screw.
Consult the applicable user manual at Consult the applicable user manual at
www.swww.sram.com/serviceram.com/service for cable and remote installation instructions. for cable and remote installation instructions.
200 Hour Service Continue the 200 Hour Service with Continue the 200 Hour Service with Lower Leg InstallationLower Leg Installation..
3
RL R
≈75°
2 mm 0.5 N·m (4 in-lb)
RL R RL R
≈20°
RL R: 2.5 mm 1.4 N·m (12 in-lb)
