VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
9-9
Vent Bi-level Floor Defroster and Floor
Mode Switch
By pressing the switches, the air flow mode changes.
Rear air conditioner
ON: “R”
Rear air conditioner
OFF
Fan speed control:
1, 2, 3 stage
Rear heater switch
• Rear heater ON
• This function is not available when the rear air conditioner
switch is at ( ) position.
Rear air conditioner switch
• Rear air conditioner OFF:
• Fan speed control: 1, 2, 3 stage
• Rear air conditioner ON: “R” position
