3-8
ENGINE HOOD
1. To open the engine hood, pull the release knob
located on left lower side of instrument panel to un-
latch the engine hood. The engine hood will then be
unlocked and partially opened.
2. Push the safety catch lever located under the hood
to the arrow direction
and lift up the engine hood.
3. To hold the engine hood in the open position, insert
the support rod
into the slot.
• An open engine hood with engine running exposes moving
parts which can crush, cut or entangle.
• Check that the engine hood is fully latched in position by
pulling at its front edge before driving.
• To avoid a personal injury, take care of the separation of
the support rod from the slot especially in windy day.
WARNING
