BULB SPECIFICATIONS AND FUNCTIONAL CHECK
BULB SPECIFICATIONS
FUNCTIONAL CHECK
1. Check whether the lamp comes on or off when its switch
operation.
2. Check the corresponding fuse when the lamp doesn’t
come on.
3. If the fuse is blown, replace it with new one. For replacing
procedures, refer to “Fuse Replacement” section in this
manual.
4. If the fuse is not blown, check the bulb and replace it with
new one if needed.
5. If the bulb is not defective, have the system checked by
Ssangyong Dealer or Ssangyong Authorized Service
Operation.
• Use only a specified capacity bulb for replacement.
• Disconnect the negative cable on the battery before replacing the
bulb.
• Do not apply excessive force to remove the bulb cover.
• Make sure that the corresponding switch and the ignition switch
are turned off before replacing a bulb.
• Do not touch a bulb with bare hands immediately after turning off
the lamp.
• Do not touch a bulb when it is still illuminating.
• Do not touch a bulb with bare hands. Fingerprint, dust, or mois-
ture stuck to bulb may shorten a bulb life or cause a bulb bursting.
In this case, wipe the bulb glass with a soft cloth.
• Never try to adjust the headlamp aiming by yourself. It should be
done by a qualified technician in Ssangyong Dealer or Ssangyong
Authorized Service Operation.
CAUTION
Description
Specification
(EU)
2
2
2
2
2
2
4
2
1
2
1
2
1
2
1
4
4
1
1
Exterior
lamp
High beam
Low beam
Turn signal lamp
Position lamp
Headlamp
Front fog lamp
Side repeater
55W
55W
27W
5W
27W
5W
8W(27W)
27W
21W
-
27W
5W
16W
10W
10W
5W
5W
5W
8W
Back-up lamp
Rear fog lamp
License plate lamp
High mounted stop lamp
Front room lamp
Glove box lamp
Door courtesy lamp
Side room lamp
Foot lamp
Rear room lamp
Tail (stop) lamp
Turn signal lamp
EU
General
Interior
lamp
Amount
Rear combina-
tion lamp
Specification
(General)
55W
55W
27W
5W
27W
5W
8W(27W)
27W
-
21W
-
5W
16W
10W
10W
5W
5W
5W
8W
