9-10
AUTOMATIC AIR CONDITIONER*
Rear Fan Control
Switch
Sun Sensor
Fault Code Display
This display blinks for about 5 seconds
when the system is defective or the engine
is started.
Air Conditioner Control Panel
Auto Button
Ambient Tem-
perature Sensor
Interior Tempera-
ture and Humidity
Sensor
• If the Auto button is pressed, the temperature of the passenger com-
partment is automatically maintained according to the set temperature.
• By operating the relevant switch of the automatic air conditioner, you can
manually control the air conditioner operation, air flow direction, fan
speed and air source.
• To turn off the air conditioner and heater, press “OFF” button ( ).
• If you use wiper during A/C operation, the air conditioner may be auto-
matically changed to defroster mode according to the wiper operating
conditions (A/C ON, fresh air intake mode).
