1 Features
• Tiny 15 mm × 42 mm standalone debugging and programming probe for STM32 microcontrollers
• Self‑powered through a USB Type-C
®
connector
• USB 2.0 high-speed interface
• Probe firmware update through USB
• Optional drag‑and‑drop Flash memory programming of binary files
• Communication bi-color LED
• JTAG communication support up to 21 MHz
• SWD (Serial Wire Debug) and SWV (Serial Wire Viewer) communication support up to 24 MHz
• Virtual COM port (VCP) up to 16 Mbps
• 1.65 to 3.60 V application voltage support
• Board connectors:
–
USB Type-C
®
connector
– 1.27 mm pitch STDC14 debug connector with STDC14 to STDC14 flat cable
– 2.0 mm pitch on-board pads for BTB (Board-to-board) card edge connector
Note: STLINK-V3MINIE does not provide any power supply to the target application.
UM2910
Features
UM2910 - Rev 2
page 2/20
