Figure 3. MB1762 top layout
Pads for BTB
connector (Top)
(CN2)
STM32F723
microcontroller
(U4)
USB Type-C
®
connector
(CN1)
COM LED
(LD1)
Power LED
(LD2)
Figure 4. MB1762 bottom layout
Pads for BTB
connector (Bottom)
(CN2)
STDC14 connector
(CN4)
UM2910
Hardware layout
UM2910 - Rev 2
page 7/20
