8 STLINK-V3MINIE board information
8.1 Product marking
The stickers located on the top or bottom side of the PCB provide product information:
• Product order code and product identification for the first sticker
• Board reference with revision, and serial number for the second sticker
On the first sticker, the first line provides the product order code, and the second line the product identification.
On the second sticker, the first line has the following format: “MBxxxx-Variant-yzz”, where “MBxxxx” is the board
reference, “Variant” (optional) identifies the mounting variant when several exist, "y" is the PCB revision and "zz"
is the assembly revision, for example B01. The second line shows the board serial number used for traceability.
Evaluation tools marked as “ES” or “E” are not yet qualified and therefore not ready to be used as reference
design or in production. Any consequences deriving from such usage will not be at ST charge. In no event, ST will
be liable for any customer usage of these engineering sample tools as reference designs or in production.
“E” or “ES” marking examples of location:
• On the targeted STM32 that is soldered on the board (For an illustration of STM32 marking, refer to the
STM32 datasheet “Package information” paragraph at the www.st.com website).
• Next to the evaluation tool ordering part number that is stuck or silk-screen printed on the board.
8.2 STLINK-V3MINIE product history
8.2.1 Product identification LKV3MINIE$KT1
This product identification is based on the MB1762 revision B-01.
Product limitation
To ensure compliance to radiated emission a USB cable featuring a ferrite clamp (magnetic ring) is mandatory.
8.3 Board revision history
8.3.1 Board MB1762 revision B-01
The revision B-01 of the MB1762 board is the first official version.
Board limitation
No limitation identified for this board revision.
UM2910
STLINK-V3MINIE board information
UM2910 - Rev 2
page 13/20
