Hardware layout and configuration UM1724
14/68 UM1724 Rev 14
Figure 4. Bottom layout
SB4, SB6, SB8, SB10
(RESERVED)
SB3, SB5, SB7, SB9
(DEFAULT)
MS34375V1
SB17
USER button
SB11
ST-LINK
RESET
SB21
USER LED
SB13, SB14
ST-LINK USART
SB15
ST-LINK SWO
SB16
ST-LINK MCO
SB50
ST-LINK MCO

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ST STM32 NUCLEO-F103RB and is the answer not in the manual?

ST STM32 NUCLEO-F103RB Specifications

General IconGeneral
MicrocontrollerSTM32F103RBT6
CoreARM Cortex-M3
Operating Voltage3.3V
Input Voltage7 - 12V
Clock Speed72 MHz
Flash Memory128 KB
RAM20 KB
Analog Input Pins16
DAC Channels2
On-board DebuggerST-LINK/V2-1
Board Size69 mm x 53 mm
Timers4
Communication InterfacesUSART, SPI, I2C
ConnectorsArduino, Morpho
Analog Inputs10
