Hardware layout and configuration UM1724
14/68 UM1724 Rev 14
Figure 4. Bottom layout
SB4, SB6, SB8, SB10
(RESERVED)
SB3, SB5, SB7, SB9
(DEFAULT)
MS34375V1
SB17
USER button
SB11
ST-LINK
RESET
SB21
USER LED
SB13, SB14
ST-LINK USART
SB15
ST-LINK SWO
SB16
ST-LINK MCO
SB50
ST-LINK MCO

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ST STM32 NUCLEO-F411RE and is the answer not in the manual?

ST STM32 NUCLEO-F411RE Specifications

General IconGeneral
MicrocontrollerSTM32F411RET6
CoreARM Cortex-M4
Operating Voltage3.3V
Input Voltage7V to 12V
Operating Frequency100 MHz
Flash Memory512 KB
SRAM128 KB
Digital I/O Pins50
Analog Input Channels16
DAC Channels1
On-board DebuggingST-LINK/V2-1
Communication InterfacesI2C, SPI, USART
USBUSB 2.0
ConnectorsArduino Uno
Form FactorNucleo
