User interface description UM0462
8/14
Step 2
The second step consists in selecting the connection settings. Select the desired UART
settings (port name, baud rate, data bits, parity and stop bits and timeout) as shown in
Figure 4. The default configuration is automatically set.
Ensure that the boot configuration pins are set correctly, then reset the device and click
“Next” to continue. If a connection has been established, the wizard moves to the next step,
otherwise a message box is displayed that indicates the error that occurred.
Figure 4. Connection settings
