ST STM32F401

Hardware layout UM1669
10/39 DocID025174 Rev 1
Figure 2. Top layout
MS32361V1
ST-LINK/V2
ST-LINK/V
2
LD1 (red/green LED)
COM
CN2
SWD connector
LD2 (red LED)
PWR
CN3
ST-LINK/DISCOVERY selector
STM32F401VCT6
LD3 (orange LED)
LD5 (red LED)
B2 reset button
LD8 (red LED)LD7 (green LED)
LD6 (blue LED)
LD4 (green LED)
B1 user button
JP2
I
DD
measurement
SB1 (B2-RESET)
5 V power supply input/output
3 V power supply output
