UM1669 Hardware layout
37
Figure 3. Bottom layout
MS32362V1
SB3, SB5, SB7, SB9
(DEFAULT)
SB10, SB11 (RX, TX)
SB2, SB4, SB6, SB8
(RESERVED)
SB15 (SWO)
SB16 (X2 crystal)
SB17 (X3 crystal)
SB18 (X3 crystal)
SB19 (BOOT0)
SB12 (STM_RST)
SB14 (X2 crystal)
SB13 (NRST)
SB20 (BOOT1)
SB21 (B1-USER)
