DocID025174 Rev 1 9/39
UM1669 Hardware layout
37
4 Hardware layout
The STM32F401 Discovery board has been designed around the STM32F401VCT6
microcontroller in a 100-pin LQFP package.
Figure 1 illustrates the connections between the STM32F401VCT6 and its peripherals (ST-
LINK/V2, pushbutton, LED, Audio DAC, USB, ST MEMS gyroscope, ST MEMS
accelerometer + magnetometer, ST MEMS microphone, and connectors).
Figure 2 and Figure 3 help you to locate these features on the STM32F401 Discovery
board.
Figure 1. Hardware block diagram
Embedded
ST-LINK/V2
STM32F401VCT6
I/O
I/O
I/O
RESET
LEDs
LD3...LD8
MP45DT02
B2
RESET
B1
USER
L3GD20
Micro-USB
Mini-USB
SWD
Header
Header
CS43L22
Mini-Jack
MS31947V2
LSM303DLHC
