ST STM32H743I-EVAL User Manual

Connectors UM2198
32/69 DocID030511 Rev 1
16 PB7 I2C_1_SDA
Remove R160, R181, R209, Disconnect
CN4, CN15, CN20
18 PB6 I2C_1_SCL
Remove R155, R180, R212, Disconnect
CN4, CN15, CN20
20 PB4 NJTRST Remove R79
22 PK5 RGB_LCD_B6 Remove R200, Disconnect CN20
24 PJ13 RGB_LCD_B1 Disconnect CN20
26 PG12 RMII_TXD1 -
28 PJ14 RGB_LCD_B2 Disconnect CN20
30 GND - -
32 PJ12 RGB_LCD_B0 Remove R25, Disconnect CN20
34 PD3 GPIO_CAN_STBY Remove R4
36 PC10 SDIO_1_D2 -
38 PA14 JTCK-SWCLK Remove R59
40 PC11 SDIO_1_D3 Open SB45
42 PC7 SDIO_1_D123DIR Remove R92
44 PC8 SDIO_1_D0 -
46 PA9 USB_FS1_VBUS Remove R255
48 +3.3V - -
50 GND - -
52 PA8 MCO1 Disconnect CN15, Keep JP5 on open
54 PA11
USB_FS1_DM/
FDCAN_1_RXFD
Open SB50, SB59
56 PA12
USB_FS1_DP/
FDCAN_1_TXFD
Keep JP2 on open, Open SB60
58 PK2 RGB_LCD_G7 Disconnect CN20
60 +5V - -
Table 22. Daughterboard extension connector CN7 (continued)
Pin Description Alternative function
How to disconnect with function block on
STM32H743I-EVAL board
