ST STM32H743I-EVAL User Manual

DocID030511 Rev 1 47/69
UM2198 STM32H743I-EVAL I/O assignment
68
D7 PK7 RGB_LCD_DE -
T1 PA0_C Potentiometer -
T2 PA1_C - -
R1 PC2_C - -
R2 PC3_C - -
Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name Default function Alternative function
