LCD-TFT display on FSMC AN4943
8/22 DocID029937 Rev 2
A typical connection is showed in Figure 2
Figure 2. Display bus interface specification
3.2 Display Command Set (DCS) software interface
The LCD-TFT displays can be controlled through the physical interface (here the FSMC
bus) using software commands according to the display command set (DCS) as defined in
the MIPI alliance specification for DCS.
The DCS commands are used to configure the display module and to transfer the frame
buffer to the display.
MSv44255V1
CSX
V
DD
RESX
TE
V
DDI
D[15:0], D[8:0] or [D[7:0]
AGND
DGND
Power block
Interface block
Host
Interface block
D/CX
WRX
RDX
Display
