6 Bill of materials
Table 3. X-NUCLEO-53L8A1 bill of materials
Item Quantity Reference Part/value Description Manufacturer Order code
1 3 C2, C4, C6 1 μF
CAP, CER, 1uF, 35V, X5R,
0402
Murata GRM155R6YA105KE11D
2 1 C3 10 μF
Capacitance, ceramic, 10 μF,
6.3 V, X5R, 0603
Kemet C0603C106M9PACTU
3 10
C8, C9, C10,
C11, C12, C13,
C14, C15, C16,
C21
100 nF
Capacitance, ceramic, 100 μF,
50 V, X5R, 0402
Murata GRM155R61H104KE19
4 1 CN5 2.54 mm, T/H, Vert
Connectors, header, 10POS,
10x1, 2.54 mm, T/H, VERT
Harwin M20-9991045
5 2 CN6, CN9 2.54 mm, T/H, Vert
Connectors, header, 08 POS,
8x1, 2.54 mm, T/H, VERT
Harwin M20-9990845
6 1 CN8 2.54 mm, T/H, Vert
Connectors, header, 06 POS,
6x1, 2.54 mm, T/H, VERT
Harwin M20-9990645
7 2 GND1, GND2 Clip TESTPOINT, CLIP, TIN, SMD Harwin S1751-46R
8 3 J1, J2, J3 2x1 2.54 mm T/H
Connectors, header, 2POS,
2.54 mm, T/H, VERT
Harwin M20-9990245
9 6
J1[1-2], J2[1-2],
J3[1-2], J7[1-2],
J8[1-2], J9[2-3]
0.1" Jumper Link Link, header, 2.54 mm Harwin M7571-05
10 2
J6_Left,
J6_Right
HDR_11x1 Female
2.54 mm
Connectors, header 11POS,
SNGL, 2.54 mm, T/H
Samtec SSW-111-01-G-S
11 3 J7, J8, J9 2.54 mm T/H
Connectors, header, 3POS,
SNGL, 2.54 mm, T/H
Harwin M20-9990345
12 2
J12_Left,
J12_Right
HDR_3x1 Female
2.54 mm
Connectors RCPT 3POS 0.1
Gold PCB
Samtec SSW-103-01-G-S
13 7
R4, R5, R6,
R14, R16, R17,
R30
47 k
Resistors, 47 k, 1 %, 1/10 W,
0402
Panasonic ERJ2RKF4702X
14 4
R2, R3, R18,
R19
2.2 k
Resistors, 2.2 k, 1 %, 1/16 W,
0402
Stackpole Electronics RMCF0402FT2K20
15 4
R20, R22, R23,
R26
10 k
Resistors, 10 k, 1 %, 1/16 W,
0402
Yageo RC0402FR-0710KL
16 2 R40, R41 1 k
Resistors, 1 k, 1 %, 1/16 W,
0402
Yageo RC0402FR-071KL
17 1 SB1[1-2] Solder bridge Link, solder N/A N/A
18 2 U1, U3
LDK130M33RY,
SOT23-5L
IC, REG, LDO, 3.3 V, 0.3 A,
SOT23-5L
ST LDK130M33RY
19 1 U2
LDK130M18R,
SOT23-5L
IC, REG, LDO, 1.8 V, 0.3 A,
SOT23-5L
ST LDK130M18R
20 1 U4 VL53L8CA
Multi-zone time-of-flight ranging
sensor
ST VL53L8CAV0GC/1
21 4 U5, U6, U7, U8 PI4ULS3V204
IC, 4-bit bi-directional level
shifter, TQFN3.5x3.5-14
Diodes Incorporated PI4ULS3V204ZBEX
22 1 C19 10 nF
Capacitor, ceramic, 10 nF, 25V,
X5R, 0402
AVX 04023D103KAT2A
23 1 R1 47 k
Resistor, 47 k, 1 %, 1/10 W,
0402
Panasonic ERJ2RKF4702X
UM3120
Bill of materials
UM3120 - Rev 1
page 14/23
