• Histogram-based technology
• I²C (up to 1 MHz) or SPI (up to 20 MHz) interface
• Multiobject detection capability
• 0.25, 0.5, and 1 mm spacers to simulate air gaps
• One cover glass to protect the sensor from dust
• Compatible with STM32 Nucleo development boards
• Equipped with Arduino UNO R3 connectors
• Full system software supplied, including code examples and graphical user interface
• RoHS, CE, UKCA, and China RoHS compliant
1.3 VL53L8 series Time-of-Flight sensor characteristics
• Laser wavelength : 940 nm
• Invisible laser radiation
• Maximum laser power emitted : 215 mW
• Integration time : 2 ms minimum
1.4 Spacers and covers
The X-NUCLEO-53L8A1 expansion board is delivered with:
• three spacers of 0.25 mm, 0.5 mm, and 1 mm height, used to simulate different air gaps between the
VL53L8 and the rectangular-shaped cover glass;
• two twelve-pin headers that allow connecting the two mini PCB of the SATEL boards to the X-
NUCLEO-53L8A1 expansion board through flying wires.
Attention: The VL53L8 is delivered with a liner to prevent potential foreign material from piercing the module holes during
the assembly process. Remove this liner before use.
1.5
Ordering information
Table 1. Ordering information
Order code
PCB version Core product
X-NUCLEO-53L8A1A X$NUCLEO-53L8A1A VL53L8
1.6 Ordering information for the VL53L8 series Time-of-Flight sensors
This board is equipped with a noncommercial VL53L8CA evaluation purposes only Time of Flight sensor. Its
equivalent orderable products are listed in the following table. For a detailed description of each sensor, please
refer to its datasheet on the product web page. Additional information is available from the user manual and
collateral documents of the target ToF sensor.
Table 2. VL53L8 series ordering information
RPN
CPN Datasheet Features
VL53L8CX VL53L8CXV0GC/1 DS14161
Low-power high-performance 8x8
multizone Time-of-Flight
UM3120
VL53L8 series Time-of-Flight sensor characteristics
UM3120 - Rev 1
page 3/23
