4 Graphical user interface (GUI) and programming example for the
X-NUCLEO-53L8A1
To evaluate the VL53L8 device performance, use the related GUI or the X-CUBE-TOF1.
The X-NUCLEO-53L8A1 expansion board requires the NUCLEO-F401RE development board to use the GUI or
run the ranging examples included in the X-CUBE-TOF1.
Important: Despite the fact that the X-NUCLEO-53L8A1 can be stacked on any STM32 Nucleo board equipped the Arduino
R3 connectors, the GUI is designed to work with the NUCLEO-F401RE only.
Download the GUI (in the Tools and Software tab of the X-NUCLEO-53L8A1 web page) or the X-CUBE-TOF1 to
evaluate the VL53L8.
UM3120
Graphical user interface (GUI) and programming example for the X-NUCLEO-53L8A1
UM3120 - Rev 1
page 8/23
