ST X-NUCLEO-53L8A1 User Manual

Setup & Demo Examples
VL53L8CX GUI software installation
• Perform the offset and Xtalk calibration and visualize calibration data
• Change key parameters of VL53L8CX
• Display real time the data (distance, signal, ambient rate)
• Get data logging and replay a datalog (.csv file)
10
• Perform HW installation and connect the X-NUCLEO-53L8A1 expansion board + Nucleo F401RE to the PC
• Install the GUI SW for VL53L8CX Demo and configuration settings
• STSW-IMG041, downloaded from www.st.com
• Run the installer with Admin privileges
GUI is generally the first and easy tool to evaluate the device
The Graphical User Interface can:
