1 Features
The X-NUCLEO-LPM01A expansion board has the following features:
• Data acquisition and data treatment unit: STM32L496VGT6 Ultra-low-power MCU with
80 MHz/100 DMIPS Arm
®
Cortex
®
-M4 core, 1 Mbyte of Flash memory, 320 Kbytes of
SRAM, 3x 12-bit ADC at 5 Msamples/s, 2 x comparators
• Programmable voltage source from 1.8 V to 3.3 V
• Static current measurement from 1 nA to 200 mA
• Dynamic measurements:
– 100 kHz bandwidth, 3.2 Msamples/s sampling rate
– Current from 100 nA to 50 mA
– Power measurement from 180 nW to 165 mW
– Energy measurement computation by power measurement time integration
• Target board connections:
– Arduino™ Nano connector (for example to connect a Nucleo-32)
– Arduino™ Uno connector (for example to co
nnect a Nucleo-64 or a Nucleo-144)
– Basic connector for wire connection to any target board
• Expansion board power supply input sour
ces (selectable via jumper) through:
– USB micro-B
– External power (Ext Pwr) connector: from 7 V to 10 V
– Arduino Uno or Arduino Nano: pin 5 V
• Standalone mode:
– Monochrome LCD, 2 lines of 16 characters with back light
– 4-direction joystick with selection button
– Enter and Reset push-buttons
• Host-controlled mode:
– Connection to a PC through USB FS micro-B receptacle
– Command line (Virtual COM port) or STM32CubeMonitor-Power PC tool.
