STA-RITE MAX-E-PRO - Repair Parts List; P6 E, P6 RA Max-E-Pro Pump Parts

14
Motor No. Impeller Diffuser
Model No. HP (Key No. 1) (Key No. 10) (Key No. 11)
115/230 Volt
P6E6C-204L 1/2 AE100CHL C105-238PX C1-271P1
P6E6D-205L 3/4 AE100DHL C105-238P C1-271P1
P6E6E-206L 1 AE100EHL C105-238PB C1-271P1
P6RA6E-205L 1 A100ELL C105-238P C1-271P1
P6RA6F-206L 1
1
⁄2 A100FLL C105-238PB C1-271P1
230 Volt
P6E6F-207L* 1
1
⁄2 AE100FHL C105-238PDBA C1-271P
P6E6G-208L* 2 AE100GHL C105-238PEBA C1-271P
P6RA6G-207L* 2 A100GHL C105-238PDBA C1-271P
P6E6H-209L* 3 AE100HLL C105-238PLA C1-271P
2-Speed
P6RA6YF-206L** 1
1
⁄2–1/4 A100FLL-Y C105-238PBA C1-271P
P6RA6YG-207L* 2–1/3 A100GLL-Y C105-238PDBA C1-271P
Parts are common to all models listed except as noted;
Key Nos. 1, Motor; 10, Impeller; and 11, Diffuser are listed below.
Key Part Part
No. Description Qty. No.
1 Motor 1 Chart at Right
2 #10-32x1/2” Screw 1 U30-692SS
2A Lock Washer 1 U43-22SS
3 Bonding Lug 1 U17-568
4 Water Slinger 1 17351-0009
5 Seal Plate Kit
(Incl. Key Nos. 6, 7) 1 C203-194P
6 O-Ring 1 U9-228A
7 Shaft Seal 1 37400-0028S
8 Clamp Knob 1 C19-37A
9 Clamp 1 WC36-22
10 Impeller 1 Chart at Right
10A Impeller Screw O-Ring 1 35505-1426
10B Impeller Screw 1 Chart at Right
11 Diffuser 1 Chart at Right
12 Diffuser O-Ring 1 U9-374
13 #8 Lock Washer 5 U43-21SS
14 Screw (w/C1-271P Diffuser) 5 U30-922SS
14 Screw (w/C1-271P1 Diffuser) 5 U30-542SS
15 Tank Body Assembly**** 1 17307-0110S
16 Trap Cover Assembly** 1 17307-0111S
17 Trap O-Ring 1 35505-1440
18 Basket 1 C8-58P
19 1/4” NPT Drain Plug 2 U178-920P
20 Base Washer 2 U43-41SS
21 Base Screw 2 U30-918SS
22 Base w/Motor Pad*** 1 C104-78P
23 Motor Pad 1 C35-43
24 3/8-16x1” Hex Hd. Screw 4 U30-74SS
• Voltage Sticker - 230 Volts
(Single voltage models only) U27-68
• Voltage Sticker - 115/230 Volts
(Dual voltage models only) U27-153
• Tag, “CAUTION, WARNING
(bonding)” 61002-0002
• Decal, “Do not overtighten...” U27-644
• Nameplate 32155-7117
REPAIR PARTS LIST
*Uses Key No. 10B Impeller Screw No. 37337-6080.
** Uses Key No. 10B Impeller Screw No. 37337-6081.
• Not illustrated.
** Includes Trap Cover, Trap Ring and Trap Cover O-Ring.
*** Model P6E6H uses Base No. C104-79P and
Motor Pad No. C35-44.
**** Includes Trap Body, Basket, Drain Plugs, and
Trap Cover Assembly.
P6E, P6RA
MAX-E-PRO
TM
POOL PUMP
1/2 through 3 HP Models
For quick disconnect pipe connections,
purchase separately:
Pkg. 188 2" Slip 1/2 Union Kit or
Pkg. 189 2" NPT 1/2 Union Kit.
Includes 2 each:
U11-200P Union Collar
U9-362 O-Ring
U11-196P 2" Slip adapter or
U11-199P 2" NPT adapter.
Box A
