6.12Trolley/crab
Wheels, wheel drive and runway
• Visual inspection of wheels for wear. See tables for limits for wear.
• Visual inspection of runway girder for wear.
Visual inspection of wheel flanges for wear.
If any one
of the limits for wear d1, b2 (b*-k) is attained, the part must be replaced.
( ) for machined faces
Fig.
Nominal value Limit for wear
d
[mm]
b
[mm]
d1
[mm]
b2
[mm]
18027,576 29,5
11003395 35
112538119 40
1
140
44,5
133
47
242,545
116044,5152 47
220042,5190 45
Bild 1
Bild 2
b
LR
W0903
Nominal value Limit for wear
Fig. d bLR b k b1 d1 b2 Max. play =b*-k
min max k
min kmax
[mm]
1 100 80
80
50
60
40
50
45
55
15
10
95 5,5
5,5
13
13
13
13
2 125 80
80
50
60
40
50
45
55
15
10
118,75 7
7
13
13
13
11
2 160 85
85
52
62
40
50
45
55
16,5
11,5)
152 8
13,5
16
18
16
18
2 200 100
100
100
54
64
74
40
50
60
45
55
65
23
18
13
190 10,5
10,5
10,5
18
18
18
18
18
14
2 315 115
115
115
54
64
74
40
50
60
45
55
65
30,5 (29)
25,5 (24)
20,5 (19)
300 13,5
13,5
13,5
18
18
18
18
18
18
2 400 118,5
118,5
118,5
65
75
85
50
60
70
55
65
75
27
,5 (26)
22,5 (2
1)
17,5 (16)
385 16
16
16
20
20
16,5
20
20
11,5
