PARTS REMOVAL AND REPLACEMENT
5. Unplug the power connector from the J2 position on the relay circuit board.
6. Loosen and remove the four mounting bolts and remove the relay/resistor
assembly from the frame.
7. Reinstall the relay/resistor assembly in the reverse order. Verify the wiring
connections before attaching the side cover.
