Stairmaster STEPMILL 7000 - Figure 10: Transmission and Alternator Assemblies

Page 71
FIGURES
Figure 10: Transmission and Alternator Assemblies
Drive Chain Assembly
Master Link
25305
Upper Sprocket Assembly
23424-03
Drive Chain
23257
Poly-V Pulley
21247
Transmission Assembly
23427
2 X 22037
2 X 22164
2 X 22435
(22038)
2 X 22026
22043
20007
20693
22042
(22036)
(22036)
(22037)
4 X 22036
(22036)
(22038)
22983
(22036)
4 X 22038
10860
22075
22146
(22164)
(22038)
(22435)
Frame
20547
22139
10059
20202
Alternator
20205
Transmission Pulley
24662
Transmission
20001
Transmission Pad
20808
4 X 22027
4 X 22028
22163
22029
22030
2 X 22191
2 X 22191
22433
20114
(22191)
Transmission Assembly Mounting to the Frame
Transmission Assembly
23591
Transmission Assembly
23591
