Stairmaster Stratus Systems - Wiring Diagram

Page 73
FUSE
BATTERY
INDUCTIVE
SWITCH
ALTERNATOR
LOAD
RESISTOR
BATTERY CHARGER
CONSOLE
POWER CONTROL BOARD
BATTERY CHARGER
PIN 1 – VDC + (WHT)
PIN 2 – GROUND
(BLK)
PIN 3 – N/C
CONSOLE
PIN 1 – VSUPPLY
(BLK)
PIN 2 – ALTERNATOR SHUTDOWN (BRN)
PIN 3 – B+ OUT (RED)
PIN 4 – RESISTOR CONTROL
(ORG)
PIN 5 – VCC (YEL)
PIN 6 – TACH (GRN)
PIN 7 – GROUND (BLU) - PIN 10 of Pwr.Con.Brd.
PIN 8 – AUXILLARY
(VIO)
PIN 9 - SHUT DOWN (GRY)
FUSE
5 Amp 250V
Re
p
lace fuse with same t
yp
e
BATTERY
PIN 1  N/C
PIN 2 – GROUND
(BLK)
PIN 3 – VDC (WHT)
INDUCTIVE SWITCH
5VAC at PINS 1 AND 2 WHILE STEPPING.
ALTERNATOR
PIN 1 – B+ (WHT)
PIN 2 – GROUND (BLK)
PIN 3 – FIELD
(BRN)
PIN 4 – N/C
LOAD RESISTOR
½ Ohm 240 Watt
½ Ohm measured at PINS 1 AND 2 of load resistor
connector.
WIRING SCHEMATIC
WIRING DIAGRAM
Wiring Diagram
