Standex MHHX030CCC - Page 25

5/16 Rev. B 57-02497 25
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a 10°
TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41)
H.P.
Connections
MCA Voltage -20 -10 0 Liquid Suction
BCLZ0400C 2DL3-040E-TFC 2DL3-040E-TFC 16677 21531 26839 R-404A C 4 5/8 1 3/8 44 208-230/60/3
BCLZ0400E 2DL3-040E-TFD 2DL3-040E-TFD 16677 21531 26839 R-404A C 4 5/8 1 3/8 22 460/60/3
BCLZ0400G 2DL3-040E-TFD 2DL3-040E-TFD 13897 17942 22365 R-404A C 4 5/8 1 3/8 22 380-420/50/3
BCLZ040LC 2DL3-040E-TFC 2DL3-040E-TFC 17743 23171 29350 R-404A C 4 5/8 1 3/8 45 208-230/60/3
BCLZ040XC 2DL3-040E-TFC 2DL3-040E-TFC 16677 21531 26839 R-404A C 4 5/8 1 3/8 44 208-230/60/3
BCLZ0600C 2DB3-060E-TFC 2DB3-060E-TFC 20522 26466 32837 R-404A C 6 5/8 1 3/8 46 208-230/60/3
BCLZ0600CC 2DB3-060E-TFC 2DB3-060E-TFC 20522 26466 32837 R-404A C 6 5/8 1 3/8 46 208-230/60/3
BCLZ0600E 2DB3-060E-TFD 2DB3-060E-TFD 20522 26466 32837 R-404A C 6 5/8 1 3/8 26 460/60/3
BCLZ0600GC 2DB3-060E-TFD 2DB3-060E-TFD 17100 22050 27360 R-404A C 6 5/8 1 3/8 26 380-420/50/3
BCLZ060LE 2DB3-060E-TFD 2DB3-060E-TFD 20522 26466 32837 R-404A D 6 7/8 1 3/8 32 460/60/3
BCLZ060VCC 2DB3-060E-TFC 2DB3-060E-TFC 20522 26466 32837 R-404A C 6 5/8 1 3/8 46 208-230/60/3
BCLZ0750C 3DB3-075E-TFC 3DB3-075E-TFC 29152 37322 46609 R-404A D 7.5 7/8 1 3/8 55 208-230/60/3
BCLZ0750E 3DB3F33KE-TFD 3DB3-075E-TFD 23100 36200 46900 R-404A D 7.5 7/8 1 3/8 32 460/60/3
BCLZ075LC 3DB3-075E-TFC 3DB3-075E-TFC 29858 38369 48233 R-404A E 7.5 7/8 1 3/8 56 208-230/60/3
BCLZ075LCR 3DB3-075E-TFC 3DB3-075E-TFC 29858 38369 48233 R-404A E 7.5 7/8 1 3/8 56 208-230/60/3
BCLZ075UC 3DB3-075E-TFC 3DB3-075E-TFC 29152 37322 46609 R-404A D 7.5 7/8 1 3/8 55 208-230/60/3
BCLZ075UE 3DB3-075E-TFD 3DB3-075E-TFD 29152 37322 46609 R-404A D 7.5 7/8 1 3/8 32 460/60/3
BCLZ0900C 3DF3A090E-TFC 3DF3A090E-TFC 35427 45657 57231 R-404A E 9 7/8 1 3/8 68 208-230/60/3
BCLZ0900E 3DF3F40KE-TFD 3DF3F40KE-TFD 35427 45657 57231 R-404A E 9 7/8 1 3/8 460/60/3
BCLZ1000C 3DS3-100E-TFC 3DS3-100E-TFC 39632 50630 62719 R-404A E 10 7/8 1 3/8 71 208-230/60/3
BCLZ1000E 3DS3-100E-TFD 3DS3-100E-TFD 39632 50630 62719 R-404A E 10 7/8 1 3/8 37 460/60/3
BCLZ1000G 3DS3-100E-TFD 3DS3-100E-TFD 33026 42191 52265 R-404A E 10 7/8 1 3/8 37 380-420/50/3
BCLZ100AC 9TH2-101E-TFC 9TH2-101E-TFC 31000 0 0 R-404A E 10 7/8 1 3/8 62 208-230/60/3
BCLZ100LC 3DS3-100E-TFC 3DS3-100E-TFC 41664 53724 67326 R-404A F 10 7/8 1 5/8 77 208-230/60/3
BCLZ100UC 3DS3-100E-TFC 3DS3-100E-TFC 39632 50630 62719 R-404A E 10 7/8 1 3/8 71 208-230/60/3
BCLZ100UE 3DS3-100E-TFD 3DS3-100E-TFD 39632 50630 62719 R-404A E 10 7/8 1 3/8 37 460/60/3
BCLZ122AC S4G-12.2Y S4G-12.2Y 43600 0 0 R-404A E 12 7/8 1 3/8 66 208-230/60/3
BCLZ122AE S4G-12.2Y S4G-12.2Y 43600 0 0 R-404A E 12 7/8 1 3/8 30 460/60/3
BCLZ1500C 4DL3-150E-TSK 4DL3-150E-TSK 56305 70782 86932 R-404A F 15 7/8 1 5/8 90 208-230/60/3
BCLZ1500E 4DL3-150E-TSK 4DL3-150E-TSK 56305 70782 86932 R-404A F 15 7/8 1 5/8 51 460/60/3
BCLZ1500G 4DL3-150E-TSK 4DL3-150E-TSK 46900 58900 72400 R-404A F 15 7/8 1 5/8 51 380-400/50/3
BCLZ150RE 4DL3-150E-TSK 4DL3-150E-TSK 56305 70782 86932 R-404A F 15 7/8 1 5/8 51 460/60/3
BCLZ150UC 4DL3-150E-TSK 4DL3-150E-TSK 56305 70782 86932 R-404A F 15 7/8 1 5/8 90 208-230/60/3
BCLZ150UE 4DL3-150E-TSK 4DL3-150E-TSK 56305 70782 86932 R-404A F 15 7/8 1 5/8 51 460/60/3
BCLZ2200C 4DT3-220E-TSK 4DT3-220E-TSK 64947 82105 100601 R-404A F 22 7/8 2 1/8 107 208-230/60/3
BCLZ2200E 4DT3-220E-TSK 4DT3-220E-TSK 64947 82105 100601 R-404A F 22 7/8 2 1/8 57 460/60/3
BCLZ220UC 4DT3-220E-TSK 4DT3-220E-TSK 64947 82105 100601 R-404A F 22 7/8 2 1/8 107 208-230/60/3
BCLZ220UE 4DT3-220E-TSK 4DT3-220E-TSK 64947 82105 100601 R-404A F 22 7/8 2 1/8 57 460/60/3
BCLZ220XC 4DT3-220E-TSK 4DT3-220E-TSK 64947 82105 100601 R-404A F 22 7/8 2 1/8 107 208-230/60/3
BCLZ2700C 6DL3-270E-TSK 6DL3-270E-TSK 83862 108351 135965 R-404A P 27 1 3/8 2 1/8 136 208-230/60/3
BCLZ2700E 6DL3-270E-TSK 6DL3-270E-TSK 83862 108351 135965 R-404A P 27 1 3/8 2 1/8 68 460/60/3
BCLZ3000C 6DT3-300E-TSK 6DT3-300E-TSK 92877 119293 148877 R-404A P 30 1 3/8 2 1/8 154 208-230/60/3
BCLZ3000E
6DT3
-
300E
-
TSK
6DT3
-
300E
-
TSK
92877
119293
148877
R
-
404A
P
30
1 3/8
2 1/8
78
460/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
