5/16 Rev. B 57-02497 26
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41)
H.P.
Connections
MCA Voltage 30 Liquid
Suction
BCMX0070B E3AM-A075-CAV KAE2-0075-CAV 6410 R-22 A .75 3/8 5/8 14 208-230/60/1
BCMX0070C E3AM-A075-TAC KAEA-0075-TAC 6410 R-22 A .75 3/8 5/8 14 208-230/60/3
BCMX0100B E3AM-A100-CAV KAM2-0100-CAV 8750 R-22 A 1 3/8 5/8 15 208-230/60/1
BCMX0100C E3AM-A100-TAC KAM1-0100-TAC 8750 R-22 A 1 3/8 5/8 15 208-230/60/3
BCMX0150B KAGB-0150-CAV KAGB-0150-CAV 9970 R-22 B 1.5 3/8 5/8 20 208-230/60/1
BCMX0150C KAGA-0150-TAC KAGA-0150-TAC 9970 R-22 B 1.5 3/8 5/8 20 208-230/60/3
BCMX0150E KAGA-0150-TAD KAGA-0150-TAD 9970 R-22 B 1.5 3/8 5/8 13 460/60/3
BCMX0200B ERC2-0200-CAB ERC2-0200-CAB 16249 R-22 C 2 1/2 7/8 29 230/60/1
BCMX0200C ERC1-0200-TAC ERC1-0200-TAC 16249 R-22 C 2 1/2 7/8 23 208-230/60/3
BCMX020XC ERC1-0200-TAC ERC1-0200-TAC 16249 R-22 C 2 1/2 7/8 23 208-230/60/3
BCMX0300B ERF2-0310-CAB ERF2-0310-CAB 23658 R-22 C 3 5/8 1 1/8 45 230/60/1
BCMX0300C ERF1-0310-TAC ERF1-0310-TAC 23658 R-22 C 3 5/8 1 1/8 45 208-230/60/3
BCMX0300E ERF1-0310-TAD ERF1-0310-TAD 23658 R-22 C 3 5/8 1 1/8 20 460/60/3
BCMX030XC ERF1-0310-TAC ERF1-0310-TAC 23658 R-22 C 3 5/8 1 1/8 45 208-230/60/3
BCMX0500C 2DC3-050E-TFC 2DC3-050E-TFC 34348 R-22 C 5 5/8 1 3/8 45 208-230/60/3
BCMX0500E 2DC3-050E-TFD 2DC3-050E-TFD 34348 R-22 C 5 5/8 1 3/8 26 460/60/3
BCMX050XC 2DC3-050E-TFC 2DC3-050E-TFC 34348 R-22 C 5 5/8 1 3/8 45 208-230/60/3
BCMX0750C 2DA3-075E-TFC 2DA3-075E-TFC 62115 R-22 D 7.5 5/8 1 3/8 64 208-230/60/3
BCMX0750E 2DA3-075E-TFD 2DA3-075E-TFD 62115 R-22 D 7.5 5/8 1 3/8 32 460/60/3
BCMX075VCC 2DA3-075E-TFC 2DA3-075E-TFC 62115 R-22 D 7.5 5/8 1 3/8 64 208-230/60/3
BCMX1000C 3DB3-100E-TFC 3DB3-100E-TFC 87629 R-22 E 10 7/8 1 3/8 82 208-230/60/3
BCMX1000CC 3DB3-100E-TFC 3DB3-100E-TFC 87629 R-22 E 10 7/8 1 3/8 82 208-230/60/3
BCMX1000E 3DB3-100E-TFD 3DB3-100E-TFD 87629 R-22 E 10 7/8 1 3/8 45 460/60/3
BCMX1200C 3DF3-1200-TFC 3DF3-1200-TFC 106882 R-22 F 12 7/8 1 5/8 88 208-230/60/3
BCMX120XE 3DK3-1200-TFD 3DK3-1200-TFD 119511 R-22 F 12 7/8 1 5/8 61 460/60/3
BCMX120YE 4P-15.2 4P-15.2 119511 R-22 F 12 7/8 1 5/8 61 460/60/3
BCMX1500C 3DS3-150E-TFC 3DS3-150E-TFC 119511 R-22 F 15 7/8 1 5/8 99 208-230/60/3
BCMX1500E 3DS3-150E-TFD 3DS3-150E-TFD 119511 R-22 F 15 7/8 1 5/8 63 460/60/3
BCMX2000C 4DA3-200E-TSK 4DA3-200E-TSK 125632 R-22 F 20 7/8 2 1/8 126 208-230/60/3
BCMX2000E 4DA3-200E-TSK 4DA3-200E-TSK 125632 R-22 F 20 7/8 2 1/8 63 460/60/3
BCMX2500C 4DH3-2500-TSK 4DH3-2500-TSK 170741 R-22 P 25 1 3/8 2 1/8 138 208-230/60/3
BCMX2500E 4DH3-2500-TSK 4DH3-2500-TSK 170741 R-22 P 25 1 3/8 2 1/8 74 460/60/3
BCMX250XC 4DH3-2500-TSK 4DH3-2500-TSK 170741 R-22 P 25 1 3/8 2 1/8 138 208-230/60/3
BCMX3000C 4DJ3-3000-TSK 4DJ3-3000-TSK 201598 R-22 P 30 1 3/8 2 1/8 164 208-230/60/3
BCMX3000E 4DJ3-3000-TSK 4DJ3-3000-TSK 201598 R-22 P 30 1 3/8 2 1/8 82 460/60/3
BCMX3500C 6DH3-3500-TSK 6DH3-3500-TSK 252557 R-22 R 35 1 5/8 2 1/8 186 208-230/60/3
BCMX3500E 6DH3-3500-TSK 6DH3-3500-TSK 252557 R-22 R 35 1 5/8 2 1/8 101 460/60/3
BCMX4000C 6DJ3-4000-TSN 6DJ3-4000-TSN 308134 R-22 R 40 1 5/8 2 1/8 251 230/60/3
BCMX4000E 6DJ3-4000-TSN 6DJ3-4000-TSN 308134 R-22 R 40 1 5/8 2 1/8 126 460/60/3
BCMY0300C 2DF3-030E-TFC 2DF3-030E-TFC 29985 R-134a C 3 7/8 1 1/8 45 208-230/60/3
BCMY030LBH 2DF3-030E-CFB 2DF3-030E-CFB 39614 R-134a C 3 5/8 1 3/8 45 230/60/1
BCMY0600C 2DB3-060E-TFC 2DB3-060E-TFC 40349 R-134a C 6 5/8 1 3/8 51 208-230/60/3
BCMY0750C 3DB3-075E-TFC 3DB3-075E-TFC 54990 R-134a D 7.5 5/8 1 3/8 64 208-230/60/3
BCMY1000C 3DS3A100E-TFC 3DS3A100E-TFC 71038 R-134a E 10 7/8 1 3/8 82 208-230/60/3
BCMZ0050B EJAM-A050-CAV HAJB-005E-CAV 4010 R-404A A .5 3/8 5/8 14 208-230/60/1
BCMZ0100B EJAM-A100-CAV KARB-010E-CAV 8750 R-404A A 1 3/8 5/8 15 208-230/60/1
BCMZ0100C EJAM-A100-TAC KARA-010E-TAC 8750 R-404A A 1 3/8 5/8 15 208-230/60/3
BCMZ0150B KAKB-021E-CAV KAKB-021E-CAV 12876 R-404A B 1.5 3/8 5/8 23 208-230/60/1
BCMZ0150C KAKA-020E-TAC KAKA-020E-TAC 12876 R-404A B 1.5 3/8 5/8 23 208-230/60/3
BCMZ0200C ERCA-021E-TAC ERCA-021E-TAC 17611 R-404A C 2 5/8 7/8 23 208-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
