5/16 Rev. B 57-02497 27
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage
30 Liquid Suction
BCMZ0200CC ERCA-021E-TAC ERCA-021E-TAC 17611 R-404A C 2HP 5/8 7/8 23 208-230/60/3
BCMZ0300B ERFB-031E-CAB ERFB-031E-CAB 24892 R-404A C 3HP 5/8 1 1/8 45 230/60/1
BCMZ0300C ERFA-031E-TAC ERFA-031E-TAC 24892 R-404A C 3HP 5/8 1 1/8 45 208-230/60/3
BCMZ0300E ERFA-031E-TAD ERFA-031E-TAD 24892 R-404A C 3HP 5/8 1 1/8 20 460/60/3
BCMZ0400C NRB2-040E-TFC NRB2-040E-TFC 32733 R-404A C 4HP 5/8 1 1/8 45 208-230/60/3
BCMZ0500C 2DC3-050E-TFC 2DC3-050E-TFC 38257 R-404A C 5HP 5/8 1 3/8 45 208-230/60/3
BCMZ0500E 2DC3-050E-TFD 2DC3-050E-TFD 38257 R-404A C 5HP 5/8 1 3/8 21 460/60/3
BCMZ0750C 2DA3-075E-TFC 2DA3-075E-TFC 63130 R-404A D 7.5HP 5/8 1 3/8 64 208-230/60/3
BCMZ0750E 2DA3-075E-TFD 2DA3-075E-TFD 63130 R-404A D 7.5HP 5/8 1 3/8 32 460/60/3
BCMZ1000C 3DB3-100E-TFC 3DB3-100E-TFC 85998 R-404A E 10HP 7/8 1 3/8 82 208-230/60/3
BCMZ1000E 3DB3-100E-TFD 3DB3-100E-TFD 85998 R-404A E 10HP 7/8 1 3/8 45 460/60/3
BCMZ1500C 3DS3-150E-TFC 3DS3-150E-TFC 121045 R-404A F 15HP 7/8 1 5/8 99 208-230/60/3
BCMZ1500E 3DS3-150E-TFD 3DS3-150E-TFD 121045 R-404A F 15HP 7/8 1 5/8 52 460/60/3
BCMZ2000C 4DA3-200E-TSK 4DA3-200E-TSK 124692 R-404A F 20HP 7/8 1 5/8 126 208-230/60/3
BCMZ2000E 4DA3-200E-TSK 4DA3-200E-TSK 124692 R-404A F 20HP 7/8 1 5/8 63 460/60/3
BCMZ4000E 6DJ3-400E-TSN 6DJ3-400E-TSN 308134 R-404A R 40HP 1 5/8 2 1/8 126 460/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
