Standex MHHX030CCC - Page 28

5/16 Rev. B 57-02497 28
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity
At Room Temp.
With a 10° TD, 90°
Ambient
Ref.
Base
Size
(See
pp.
39-41)
H.P.
Connections
MCA Voltage
35
40
Liquid
Suction
BHH-030VCC CR41KQ-TF5 CR41KQ-TF5 26966 29962 R-22 C 3 1/2 7/8 20 200-230/60/3
BHH-050VCC CRN5-0500-TF5 CRN5-0500-TF5 42307 47008 R-22 C 5 5/8 7/8 32 200-230/60/3
BHHX0070B F3AH-A078-IAV RS47C2-IAV 6417 7130 R-22 A .75 3/8 5/8 10 208-230/60/1
BHHX0070B F3AH-A078-IAV RS47C2-IAV 6417 7130 R-22 A .75 3/8 5/8 10 208-230/60/1
BHHX0070K F3AH-A078-IAZ RSE4-0076-IAZ 6417 7130 R-22 A .75 3/8 5/8 11 200-220/50/1
BHHX0100B F3AM-A105-CFV RS70C1-PFV 9630 10700 R-22 N 1 3/8 7/8 11 208-230/60/1
BHHX0100C F3AM-A105-TFC REK3-0125-TFC 9630 10700 R-22 N 1 3/8 7/8 8 208-230/60/3
BHHX0150B F3AD-A151-CFV CR18KQ-PFV 12195 13550 R-22 N 1.5 3/8 7/8 16 208-230/60/1
BHHX0150C F3AD-A151-TFC CR18KQ-TF5 12195 13550 R-22 N 1.5 3/8 7/8 10 208-230/60/3
BHHX015VCC F3AH-B151-TFC CR18KQ-TF5 12195 13550 R-22 N 1.5 3/8 7/8 10 208-230/60/3
BHHX015LB CR18KQ-PFV CR18KQ-PFV 13367 14852 R-22 C 2 3/8 5/8 17 208-230/60/1
BHHX015LC CR18KQ-TF5 CR18KQ-TF5 13367 14852 R-22 C 1.5 3/8 5/8 10 208-230/60/3
BHHX0200B CR24KQ-PFV CR24KQ-PFV 21591 23990 R-22 C 2 3/8 5/8 20 208-230/60/1
BHHX0200C CR24KQ-TF5 CR24KQ-TF5 21591 23990 R-22 C 2 3/8 5/8 13 200-230/60/3
BHHX0200CC CR24KQ-PFV CR24KQ-PFV 21591 23990 R-22 C 2 3/8 5/8 20 200-230/60/3
BHHX020LC CR24KQ-TF5 CR24KQ-TF5 22131 24590 R-22 C 2 3/8 5/8 13 200-230/60/3
BHHX0250B CR33KQ-PFV CR37KQ-PFV 23903 26559 R-22 C 2.5 1/2 7/8 23 208-230/60/1
BHHX0250C CR33KQ-TF5 CR37KQ-TF5 23903 26559 R-22 C 2.5 1/2 7/8 17 200-230/60/3
BHHX025LB CR33KQ-PFV CR37KQ-PFV 24378 27087 R-22 C 2.5 1/2 7/8 23 208-230/60/1
BHHX025LC CR33KQ-TF5 CR37KQ-TF5 24378 27087 R-22 C 2.5 1/2 7/8 17 200-230/60/3
BHHX025VCC CR33KQ-PFV CR37KQ-TF5 23903 26559 R-22 C 2.5 1/2 7/8 23 200-230/60/3
BHHX025XB CR33KQ-TF5 CR37KQ-PFV 23903 26559 R-22 C 2.5 1/2 7/8 17 208-230/60/1
BHHX0300B CR41KQ-PFV CR41KQ-PFV 26966 29962 R-22 C 3 1/2 7/8 28 208-230/60/1
BHHX0300C CR41KQ-TF5 CR41KQ-TF5 26966 29962 R-22 C 3 1/2 7/8 20 200-230/60/3
BHHX0300E CR41KQ-TFD CR41KQ-TFD 26966 29962 R-22 C 3 1/2 7/8 10 460/60/3
BHHX030LC CR41KQ-TF5 CR41KQ-TF5 28004 31115 R-22 C 3 1/2 7/8 20 200-230/60/3
BHHX030RC CR41KQ-TF5 CR41KQ-TF5 26966 29962 R-22 C 3 1/2 7/8 20 200-230/60/3
BHHX030VCC CR41KQ-TF5 CR41KQ-TF5 26966 29962 R-22 C 3 1/2 7/8 20 200-230/60/3
BHHX030XB CR41KQ-PFV CR41KQ-PFV 26966 29962 R-22 C 3 1/2 7/8 28 208-230/60/1
BHHX0400B CR53KQ-PFV CRM3-0400-PFV 34661 38512 R-22 C 4 5/8 7/8 40 208-230/60/1
BHHX0400C CR53KQ-TF5 CRM3-0400-TF5 34661 38512 R-22 C 4 5/8 7/8 26 200-230/60/3
BHHX040VCC CR53KQ-TF5 CRM3-0400-TF5 34661 38512 R-22 C 4 5/8 7/8 26 200-230/60/3
BHHX040XB CR53KQ-PFV CRM3-0400-PFV 34661 38512 R-22 C 4 5/8 7/8 40 208-230/60/1
BHHX0500B CRN5-0500-PFV CRN5-0500-PFV 42307 47008 R-22 C 5 5/8 7/8 49 208-230/60/1
BHHX0500C CRN5-0500-TF5 CRN5-0500-TF5 42307 47008 R-22 C 5 5/8 7/8 32 200-230/60/3
BHHX0500CC CRN5-0500-TF5 CRN5-0500-TF5 42307 47008 R-22 C 5 5/8 7/8 32 200-230/60/3
BHHX0500E CRN5-0500-TFD CRN5-0500-TFD 42307 47008 R-22 C 5 5/8 7/8 15 460/60/3
BHHX050LC CRN5-0500-TF5 CRN5-0500-TF5 46136 51262 R-22 E 5 5/8 7/8 34 200-230/60/3
BHHX050LE CRN5-0500-TFD CRN5-0500-TFD 46136 51262 R-22 E 5 5/8 7/8 16 460/60/3
BHHX050RC CRN5-0500-TF5 CRN5-0500-TF5 42307 47008 R-22 C 5 5/8 7/8 32 200-230/60/3
BHHX050VCC CRN5-0500-TF5 CRN5-0500-TF5 42307 47008 R-22 C 5 5/8 7/8 32 200-230/60/3
BHHY0050B
FTAM
-
A059
-
IAV
RS40C1E
-
IAV
5139
5710
R134a
A
.5
1/4
1/2
8
208
-
230/60/1
BHHY0070B
AJA7465YXD
AJA7461YXD
6543
7270
R134a
A
.75
3/8
5/8
10
208
-
230/60/1
BHHY0100B FTAH-A100-CAV RR10K1E-CAV 7002 7780 R-134a N 1 3/8 5/8 11 208-230/60/1
BHHZ0070B FJAF-A078-CAV RS55-C1E-CAV 7395 8217 R-404A A .75 3/8 5/8 10 208-230/60/1
BHHZ0100B FJAM-A125-CFV RS70-C1E-CAV 9723 10803 R-404A N 1 3/8 5/8 11 208-230/60/1
BHHZ0100C FJAM-A125-TFC RS70-C1E-TFC 9723 10803 R-404A N 1 3/8 5/8 8 208-230/60/3
BHHZ0150B FJAM-A150-CFV CS10K6E-PFV 12976 14418 R-404A N 1.5 3/8 7/8 16 208-230/60/1
BHHZ0150C FJAM-A150-TFC CS10K6E-TF5 12976 14418 R-404A N 1.5 3/8 7/8 12 208-230/60/3
BHHZ015CB FJAM-A150-CFV CS10K6E-PFV 12976 14418 R-404A N 1.5 3/8 7/8 16 208-230/60/1
BHHZ015UC FJAM-A150-TFC CS10K6E-TF5 12976 14418 R-404A N 1.5 3/8 7/8 12 208-230/60/3
BHHZ015UE FJAM-A150-TFD CS10K6E-TFD 12976 14418 R-404A N 1.5 3/8 7/8 6 460/60/3
