5/16 Rev. B 57-02497 29
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity
At Room Temp.
With a 10° TD, 90°
Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage
35 40 Liquid Suction
BHHZ0200B CS12K6E-PFV CS12K6E-PFV 16488 18320 R-404A C 2 3/8 5/8 18 208-230/60/1
BHHZ0200C CS12K6E-TF5 CS12K6E-TF5 16488 18320 R-404A C 2 3/8 5/8 13 200-230/60/3
BHHZ020FB CS12K6E-PFV CS12K6E-PFV 16488 18320 R-404A C 2 3/8 5/8 18 208-230/60/1
BHHZ0250B CS14K6E-PFV CS14K6E-PFV 18060 20067 R-404A C 2.5 1/2 7/8 19 208-230/60/1
BHHZ0250C CS14K6E-TF5 CS14K6E-TF5 18060 20067 R-404A C 2.5 1/2 7/8 15 200-230/60/3
BHHZ0300B CS20K6E-PFV CS20K6E-PFV 26396 29329 R-404A C 3 1/2 7/8 27 208-230/60/1
BHHZ0300C CS20K6E-TF5 CS20K6E-TF5 26396 29329 R-404A C 3 1/2 7/8 18 200-230/60/3
BHHZ0400B CS27K3E-PFV CS27K3E-PFV 32827 36474 R-404A C 4 5/8 7/8 34 208-230/60/1
BHHZ0400C CS27K3E-TF5 CS27K3E-TF5 32827 36474 R-404A C 4 5/8 7/8 24 200-230/60/3
BHHZ0500B CS33K3E-PFV CS33K3E-PFV 37373 41525 R-404A C 5 5/8 7/8 42 208-230/60/1
BHHZ0500C CS33K3E-TF5 CS33K3E-TF5 37373 41525 R-404A C 5 5/8 7/8 30 200-230/60/3
BHHZ050LC CS33K3E-TF5 CS33K3E-TF5 40010 44455 R-404A C 5 5/8 7/8 30 200-230/60/3
* Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity
At Room Temp. With a
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp. 39-
41) H.P.
Connections
MCA Voltage
-20 -10 0 Liquid
Suction
BHLZ0070B FJAF-A078-CAV RS55C1E-CAV 2181 3253 R-404A A .75 3/8 5/8 14 208-230/60/1
BHLZ0100B FJAM-A125-CFV RS70C1E-CAV 2957 4353 R-404A N 1 3/8 5/8 14 208-230/60/1
BHLZ0100C FJAM-A125-TFC RS70C1E-TFC 2957 4353 R-404A N 1 3/8 5/8 11 208-230/60/3
BHLZ0150B FJAM-A150-CFV CS10K6E-PFV 3549 5247 R-404A N 1.5 3/8 7/8 19 208-230/60/1
BHLZ0150C FJAM-A150-TFC CS10K6E-TF5 3549 5247 R-404A N 1.5 3/8 7/8 15 208-230/60/3
BHLZ0200B AVA2510ZXNXC AVA2510ZXN 5750 7500 9500 R-404A N 2 3/8 7/8 28 208-230/60/1
BHLZ0200C AVA2510ZXFXC AVA2510ZXF 5750 7500 9500 R-404A N 2 3/8 7/8 20 208-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
