CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity
At Room Temp. With
a 10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage 30 Liquid Suction
BHM-025NC CRG3-0250-TF5 CRG3-0250-TF5 17907 R-22 C 2.5 1/2 7/8 22 200-230/60/3
BHM-050VCC CRN5-0500-TF5 CRN5-0500-TF5 38129 R-22 C 5 5/8 7/8 51 200-230/60/3
BHMX0070B F3AH-A078-IAV RSE4-0076-IAV 5760 R-22 A .75 3/8 5/8 15 208-230/60/1
BHMX0100B F3AM-A105-CFV REK3-0125-PFV 8540 R-22 N 1 3/8 5/8 15 208-230/60/1
BHMX0100C F3AM-A105-TFC REK3-0125-TFC 8540 R-22 N 1 3/8 5/8 15 208-230/60/3
BHMX0150B F3AD-A151-CFV CRA1-0150-PFV 10800 R-22 N 1.5 3/8 7/8 24 208-230/60/1
BHMX0150C F3AD-A151-TFC CRA1-0150-TFC 10800 R-22 N 1.5 3/8 7/8 20 208-230/60/3
BHMX015LC CRA1-0150-TFC CRA1-0150-TFC 11535 R-22 C 1.5 3/8 5/8 20 208-230/60/3
BHMX0200B CRD1-0200-PFV CRD1-0200-PFV 14049 R-22 C 2 3/8 5/8 29 208-230/60/1
BHMX0200C CRD1-0200-TF5 CRD1-0200-TF5 14049 R-22 C 2 3/8 5/8 23 200-230/60/3
BHMX020LB CRD1-0200-PFV CRD1-0200-PFV 14417 R-22 C 2 1/2 7/8 28 208-230/60/1
BHMX020NB CRD1-0200-PFV CRD1-0200-PFV 14049 R-22 C 2 3/8 5/8 24 208-230/60/1
BHMX020NC CRD1-0200-TF5 CRD1-0200-TF5 14049 R-22 C 2 3/8 5/8 18 200-230/60/3
BHMX020VCV CRD1-0200-TF5 CRD1-0200-TF5 14700 R-22 A 2 3/8 5/8 13 200-230/60/3
BHMX020YC CRD1-0200-TF5 CRD1-0200-TF5 14049 R-22 C 2 5/8 7/8 23 200-230/60/3
BHMX0250B CRG3-0250-PFV CRG3-0250-PFV 17907 R-22 C 2.5 1/2 7/8 31 208-230/60/1
BHMX0250C CRG3-0250-TF5 CRG3-0250-TF5 17907 R-22 C 2.5 1/2 7/8 24 200-230/60/3
BHMX025LB CRG3-0250-PFV CRG3-0250-PFV 18766 R-22 C 2.5 1/2 7/8 31 208-230/60/1
BHMX025NB CRG3-0250-PFV CRG3-0250-PFV 17907 R-22 C 2.5 1/2 7/8 28 208-230/60/1
BHMX025NC CRG3-0250-TF5 CRG3-0250-TF5 17907 R-22 C 2.5 1/2 7/8 22 200-230/60/3
BHMX025VCV CRG3-0250-TF5 CRG3-0250-TF5 17907 R-22 A 2.5 1/2 7/8 23 200-230/60/3
BHMX025XC CRG3-0250-TF5 CRG3-0250-TF5 17907 R-22 C 2.5 1/2 7/8 22 200-230/60/3
BHMX0300B CRK3-0325-PFV CRK3-0325-PFV 23419 R-22 C 3 1/2 7/8 45 208-230/60/1
BHMX0300C CRK3-0325-TF5 CRK3-0325-TF5 23419 R-22 C 3 1/2 7/8 45 200-230/60/3
BHMX0300CC CRK3-0325-TF5 CRK3-0325-TF5 23419 R-22 C 3 1/2 7/8 45 200-230/60/3
BHMX0300E CR41KQ-TFD CR41KQ-TFD 23419 R-22 C 3 1/2 7/8 10 460/60/3
BHMX030VCC CRK3-0325-TF5 CRK3-0325-TF5 23419 R-22 C 3 1/2 7/8 39 200-230/60/3
BHMX0400B CRM3-0400-PFV
CRM3
-
0400
-
PFV
30337 R-22 C 4 5/8 7/8 49 208-230/60/1
BHMX0400C CRM3-0400-TF5 CRM3-0400-TF5 30337 R-22 C 4 5/8 7/8 45 200-230/60/3
BHMX040VCV CRK3-0325-TF5 CRK3-0325-TF5 23419 R-22 A 4 5/8 7/8 26 200-230/60/3
BHMX0500B CRN5-0500-PFV CRN5-0500-PFV 38129 R-22 C 5 5/8 7/8 49 208-230/60/1
BHMX0500C CRN5-0500-TF5 CRN5-0500-TF5 38129 R-22 C 5 5/8 7/8 45 200-230/60/3
BHMX050VCC CRN5-0500-TF5 CRN5-0500-TF5 38129 R-22 C 5 5/8 7/8 51 200-230/60/3
BHMX050VCK CRN5-0500-TF5 CRN5-0500-TF5 41218 R-22 E 5 5/8 7/8 51 200-230/60/3
BHMX050VCV CRN5-0500-TF5 CRN5-0500-TF5 38129 R-22 A 5 5/8 7/8 50 200-230/60/3
BHMX050WC F3WD-0501-TFC CRN5-0500-TF5 38700 R-22 C 5 3/8 1 1/8 50 208-230/60/3
BHMZ0070B FJAF-A078-CAV RS55C1E-CAV 6727 R-404A A .75 3/8 5/8 15 208-230/60/1
BHMZ0100C FJAM-A125-TFC RS70C1E 7880 R-404A N 1 3/8 7/8 15 208-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
