Standex MHHX030CCC - Page 31

5/16 Rev. B 57-02497 31
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model
Compressor
Model
BTU/HR Capacity At
Room Temp. With a 10°
TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage 30 35 40 Liquid Suction
BSHX020VCC ZB15KCE-TF5 ZB15KCE-TF5 18000 20000 R-22 C 2 5/8 7/8 15 200-230/60/3
BSHX020VCW ZB15KCE-TF5 ZB15KCE-TF5 19600 21700 R-22 C 2 1/2 7/8 10 200-230/60/3
BSHX025VCC ZB19KCE-TF5 ZB19KCE-TF5 20200 22400 R-22 C 2.5 5/8 7/8 13 200-230/60/3
BSHX025VCC ZB19KCE-TF5 2 X E1HX009VA 20200 22400 R-22 C 2.5 5/8 7/8 13 200-230/60/3
BSHX025VCW ZB19KCE-TF5 2 X E1HX009VA 22000 24300 R-22 C 2.5 1/2 7/8 9 200-230/60/3
BSHX0300C ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-22 C 3 5/8 7/8 18 200-230/60/3
BSHX030LC ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-22 C 3 5/8 7/8 19 200-230/60/3
BSHX030LCC ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-22 C 3 5/8 7/8 19 200-230/60/3
BSHX030VCC ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-22 C 3 5/8 7/8 18 200-230/60/3
BSHX030VCW ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-22 C 3 5/8 7/8 15 200-230/60/3
BSHX030VEC ZB21KCE-TFD ZB21KCE-TFD 26190 29100 R-22 C 3 5/8 7/8 10 460/60/3
BSHX035VCC ZB26KCE-TF5 ZB26KCE-TF5 30240 33600 R-22 C 3.5 5/8 7/8 23 200-230/60/3
BSHX0500B ZB38KCE-PFV ZB38KCE-PFV 41760 46400 R-22 C 5 5/8 7/8 45 208-230/60/1
BSHX0500C ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 C 5 5/8 7/8 32 200-230/60/3
BSHX050LCC ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 D 5 5/8 7/8 32 200-230/60/3
BSHX050VCC ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 C 5 5/8 7/8 30 200-230/60/3
BSHX050VCD ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 C 5 5/8 7/8 30 200-230/60/3
BSHX050VCK ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 E 5 5/8 7/8 45 200-230/60/3
BSHX050VCW ZB38KCE-TF5 ZB38KCE-TF5 43650 48500 R-22 C 5 5/8 7/8 25 200-230/60/3
BSHX050VEC ZB38KCE-TFD ZB38KCE-TFD 43650 48500 R-22 C 5 5/8 7/8 15 460/60/3
BSHX060LCC ZB45KCE-TF5 ZB45KCE-TF5 52200 58000 R-22 E 6 7/8 1 1/8 31 200-230/60/3
BSHX060VCC ZB45KCE-TF5 ZB45KCE-TF5 52200 58000 R-22 D 6 5/8 7/8 32 200-230/60/3
BSHX060VCW ZB45KCE-TF5 ZB45KCE-TF5 52200 58000 R-22 D 6 5/8 7/8 28 200-230/60/3
BSHX0750C ZB56KCE-TWC ZB56KCE-TWC 62100 69000 R-22 E 7.5 7/8 1 1/8 45 208-230/60/3
BSHX0750VCW ZB56KCE-TWC ZB56KCE-TWC 62100 69000 R-22 D 7.5 7/8 1 1/8 40 208-230/60/3
BSHX075CCC ZB56KCE-TWC ZB56KCE-TWC 62100 69000 R-22 E 7.5 7/8 1 1/8 45 208-230/60/3
BSHX075VCC ZB56KCE-TWC ZB56KCE-TWC 62100 69000 R-22 E 7.5 7/8 1 1/8 45 208-230/60/3
BSHX1000C ZB75KCE-TWC ZB75KCE-TWC 83700 93000 R-22 F 10 7/8 1 1/8 61 208-230/60/3
BSHX100CCC ZB75KCE-TWC ZB75KCE-TWC 83700 93000 R-22 F 10 7/8 1 1/8 61 208-230/60/3
BSHX100VCC ZB75KCE-TWC ZB75KCE-TWC 83700 93000 R-22 F 10 7/8 1 1/8 61 208-230/60/3
BSHX100VCW ZB75KCE-TWC ZB75KCE-TWC 83700 93000 R-22 D 10 7/8 1 1/8 208-230/60/3
BSHX130VCC ZB92KCE-TWC ZB92KCE-TWC 106200 118000 R-22 F 13 7/8 1 1/8 71 208-230/60/3
BSHZ020UC ZB15KCE-TF5 ZB15KCE-TF5 16300 18150 20000 R-404A C 2 1/2 7/8 16 200-230/60/3
BSHZ020UE ZB15KCE-TFD ZB15KCE-TFD 16300 18150 20000 R-404A C 2 1/2 7/8 16 460/60/3
BSHZ020VCC ZB15KCE-TF5 ZB15KCE-TF5 18000 20000 R-404A C 2 5/8 7/8 15 200-230/60/3
BSHZ0250C ZB19KCE-TF5 ZB19KCE-TF5 20600 22800 25000 R-404A C 2.5 1/2 7/8 16 200-230/60/3
BSHZ0250VCC ZB19KCE-TF5 ZB19KCE-TF5 20600 22800 25000 R-404A C 2.5 1/2 7/8 16 200-230/60/3
BSHZ0300C ZB21KCE-TF5 ZB21KCE-TF5 24500 27150 29800 R-404A C 3 1/2 7/8 18 200-230/60/3
BSHZ030VCC ZB21KCE-TF5 ZB21KCE-TF5 26190 29100 R-404A C 3 5/8 7/8 22 200-230/60/3
BSHZ050VEC ZB38KCE-TFD ZB38KCE-TFD 43650 48500 R-404A C 5 5/8 7/8 15 460/60/3
BSHZ060VCC ZB45KCE-TF5 ZB45KCE-TF5 52200 58000 R-404A D 6 5/8 7/8 38 200-230/60/3
BSHZ075VCC ZB56KCE-TWC ZB56KCE-TWC 62100 69000 R-404A E 7.5 7/8 1 1/8 45 208-230/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
