Standex MHHX030CCC - Page 32

5/16 Rev. B 57-02497 32
CONDENSING UNIT SPECIFICATIONS (cont.)
Master-Bilt
®
Model
Cond Unit/Comp
Model Compressor Model
BTU/HR Capacity At
Room Temp. With a
10° TD, 90° Ambient
Ref.
Base
Size
(See
pp.
39-41) H.P.
Connections
MCA Voltage
-20 -10 0 Liquid Suction
BSLZ0200C ZF06K4E-TF5 ZF06K4E-TF5 5994 7535 9250 R-404A B 2 3/8 7/8 17 200-230/60/3
BSLZ028VCC ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 3 1/2 7/8 32 200-230/60/3
BSLZ0300B ZF09K4E-PFV ZF09K4E-PFV 8590 10734 13175 R-404A C 3 1/2 7/8 29 208-230/60/1
BSLZ0300C ZF09K4E-TF5 ZF09K4E-TF5 8590 10734 13175 R-404A C 3 1/2 7/8 23 200-230/60/3
BSLZ0300E ZF09K4E-TFD ZF09K4E-TFD 8590 10734 13175 R-404A C 3 1/2 7/8 15 460/60/3
BSLZ030VCC ZF09K4E-TF5 ZF09K4E-TF5 8590 10734 13175 R-404A C 3 1/2 7/8 23 200-230/60/3
BSLZ030VCJ ZF09K4E-TF5 ZF09K4E-TF5 8590 10734 13175 R-404A C 3 1/2 7/8 23 200-230/60/3
BSLZ030VCW ZF09K4E-TF5 ZF09K4E-TF5 8590 10734 13175 R-404A C 3 1/2 7/8 20 200-230/60/3
BSLZ030VEC ZF09K4E-TFD ZF09K4E-TFD 8590 10734 13175 R-404A C 3 1/2 7/8 15 460/60/3
BSLZ0350B ZF11K4E-PFV ZF11K4E-PFV 10369 12873 15673 R-404A C 3.5 1/2 7/8 35 208-230/60/1
BSLZ0350C ZF11K4E-TF5 ZF11K4E-TF5 10369 12873 15673 R-404A C 3.5 1/2 7/8 26 200-230/60/3
BSLZ0350E ZF11K4E-TFD ZF11K4E-TFD 10369 12873 15673 R-404A C 3.5 1/2 7/8 17 460/60/3
BSLZ0400B ZF13K4E-PFV ZF13K4E-PFV 11758 15047 18615 R-404A C 4 1/2 7/8 42 208-230/60/1
BSLZ0400C ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 4 1/2 7/8 32 200-230/60/3
BSLZ0400E ZF13K4E-TFD ZF13K4E-TFD 11758 15047 18615 R-404A C 4 1/2 7/8 20 460/60/3
BSLZ040CCC ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 4 1/2 7/8 32 200-230/60/3
BSLZ040VCC ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 4 1/2 7/8 32 200-230/60/3
BSLZ040VCC ZF13K4E-TF5 1 x TEL-5-24 11758 15047 18615 R-404A C 4 1/2 7/8 20 200-230/60/3
BSLZ040VCJ ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 4 1/2 7/8 32 200-230/60/3
BSLZ040VCW ZF13K4E-TF5 EVRZ0120BP(RCD) 11758 15047 18615 R-404A C 4 1/2 7/8 25 200-230/60/3
BSLZ040VCW ZF13K4E-TF5 ZF13K4E-TF5 11758 15047 18615 R-404A C 4 1/2 7/8 25 200-230/60/3
BSLZ040VEC ZF13K4E-TFD ZF13K4E-TFD 11758 15047 18615 R-404A C 4 1/2 7/8 20 460/60/3
BSLZ0500B ZF15K4E-PFV ZF15K4E-PFV 14572 18124 22087 R-404A C 5 1/2 7/8 54 208-230/60/1
BSLZ0500C ZF15K4E-TF5 ZF15K4E-TF5 14572 18124 22087 R-404A C 5 1/2 7/8 39 200-230/60/3
BSLZ0500E ZF15K4E-TFD ZF15K4E-TFD 14572 18124 22087 R-404A C 5 1/2 7/8 22 460/60/3
BSLZ050VCC ZF15K4E-TF5 ZF15K4E-TF5 14572 18124 22087 R-404A C 5 1/2 7/8 39 200-230/60/3
BSLZ0600C ZF18K4E-TF5 ZF18K4E-TF5 17375 21651 26380 R-404A C 6 1/2 7/8 41 200-230/60/3
BSLZ0600E ZF18K4E-TFD ZF18K4E-TFD 17375 21651 26380 R-404A C 6 1/2 7/8 21 460/60/3
BSLZ060VCC ZF18K4E-TF5 ZF18K4E-TF5 17375 21651 26380 R-404A C 6 1/2 7/8 41 200-230/60/3
BSLZ0750C ZF24K4E-TWC ZF24K4E-TWC 20911 26006 31717 R-404A D 7.5 7/8 1 3/8 45 208-230/60/3
BSLZ0750E ZF24K4E-TWD ZF24K4E-TWD 20911 26006 31717 R-404A D 7.5 7/8 1 3/8 30 460/60/3
BSLZ075VCC ZF24K4E-TWC ZF24K4E-TWC 20911 26006 31717 R-404A D 7.5 7/8 1 3/8 45 208-230/60/3
BSLZ1500C ZF48K4E-TWC ZF48K4E-TWC 42600 54000 68000 R-404A F 15 7/8 1 3/8 88 208-230/60/3
BSLZR150C ZF48KVE-TWC-
551
ZF48KVE-TWC-551 63500 78500 95500 R-404A F 15 7/8 1 3/8 81 208-230/60/3
BSLZ150VEC ZF48K4E-TWD-
551
ZF48K4E-TWD-551 42600 54000 68000 R-404A F 15 7/8 1 3/8 42 460/60/3
BSRZ150VEC ZF48K4E-TWD-
551
ZF48K4E-TWD-551 42600 54000 68000 R-404A F 15 7/8 1 3/8 42 460/60/3
*Deduct 7% for each 10 degree rise over 90°F.
**MCA does not include evaporator amps for room temperature 35°F and above.
