Stanford Research Systems PS310 - HV Board - PS310, PS325, PS350

36
No.
REF. SRS part # VALUE DESCRIPTION
8. D 8 3-00012-306 GREEN LED, Rectangular
9. D 9 3-00012-306 GREEN LED, Rectangular
10. D 10 3-00013-306 RED LED, Rectangular
11. D 11 3-00175-306 YELLOW LED, Rectangular
12. D 12 3-00013-306 RED LED, Rectangular
13. D 13 3-00013-306 RED LED, Rectangular
14. D 14 3-00004-301 1N4148 Diode
15. D 15 3-00004-301 1N4148 Diode
16. D 16 3-00004-301 1N4148 Diode
17. J 1 1-00038-130 40 PIN DIL Connector, Male
18. PC1 7-00163-701 PS300-2 Printed Circuit Board
19. R 1 4-00076-401 390 Resistor, Carbon Film, 1/4W, 5%
20. R 2 4-00076-401 390 Resistor, Carbon Film, 1/4W, 5%
21. SW18 2-00029-221 1808.0202 SWITCH, ROCKER MOM ON-OFF-ON
22. U 1 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
23. U 2 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
24. U 3 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
25. U 4 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
26. U 5 3-00289-340 HDSP-H107 Integrated Circuit (Thru-hole Pkg)
27. U 6 3-00290-340 HDSP-A101 Integrated Circuit (Thru-hole Pkg)
28. U 7 3-00290-340 HDSP-A101 Integrated Circuit (Thru-hole Pkg)
29. U 8 3-00290-340 HDSP-A101 Integrated Circuit (Thru-hole Pkg)
30. U 9 3-00290-340 HDSP-A101 Integrated Circuit (Thru-hole Pkg)
31. U 10 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
32. U 11 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
33. U 12 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
34. U 13 3-00288-340 HDSP-H101 Integrated Circuit (Thru-hole Pkg)
35. Z 0 0-00096-041 #4 SPLIT Washer, Split
36. Z 0 0-00110-053 1-1/2" #24 Wire #24 UL1007 Strip 1/4x1/4 Tin
37. Z 0 0-00187-021 4-40X1/4PP Screw, Panhead Phillips
38. Z 0 0-00209-021 4-40X3/8PP Screw, Panhead Phillips
39. Z 0 0-00254-044 PS300 Window
40. Z 0 7-00162-740 PS300-3 Keypad, Conductive Rubber
41. Z 0 7-00175-709 PS325 Lexan Overlay
42. Z 0 7-00208-709 PS310 Lexan Overlay
43. Z 0 7-00209-709 PS350 Lexan Overlay
44. Z 0 7-00231-710 PS300-50 Front Panel
PS310 HV Board Parts List
No. REF. SRS part # VALUE DESCRIPTION
1. C 1 5-00174-538 .1U Capacitor, metal film, 2000 volts
2. C 2 5-00174-538 .1U Capacitor, metal film, 2000 volts
3. C 3 5-00174-538 .1U Capacitor, metal film, 2000 volts
4. C 4 5-00174-538 .1U Capacitor, metal film, 2000 volts
5. C 5 5-00276-560 .0033U Capacitor, Ceramic Disc, 3KV
6. C 6 5-00098-517 10U Capacitor, Tantalum, 35V, 20%, Rad
7. C 7 5-00098-517 10U Capacitor, Tantalum, 35V, 20%, Rad
8. D 1 3-00284-301 ESJC04-05 Diode
