SERIES PS300 SPECIFICATIONS
General Information
The PS300 series are programmable precision high voltage power supplies for use in laboratory or test
applications. They feature reversible polarity, excellent regulation and low output voltage ripple. The digital
displays provide accurate readings of voltage and current. Also, digital entry of the current and voltage
provides accurate resettability. Output voltage can be set from either the front panel, the remote analog voltage,
or over the optional GPIB interface. Voltage and current signals are also available for remote monitoring.
Electrical Specifications
Model Output Voltage Maximum Output Current
PS310 50 to ±1250 Volts 20 mA
PS325 50 to ±2500 Volts 10 mA
PS350 50 to ±5000 Volts 5 mA
Voltage Set Accuracy 0.01% + 0.05% of full scale
Voltage Display Accuracy V Set Accuracy ±1 Volt, typ ( ±2 Volt, max)
Voltage Resolution 1 Volt (set and display)
Voltage Resettability 1 Volt
Voltage Limit Range 0 to 100% of full scale
Voltage Regulation (*) Line: 0.001% for ±10% line voltage change
Load: 0.005% for 100% load change, typ
Output Ripple < 0.0015% of full scale, Vrms, typ
< 0.002% of full scale, Vrms, max
Current Limit and Trip Range 0 to 105% of full scale
Current Set accuracy 0.01% + 0.05% of full scale
Current Resolution PS310: 10 µA
PS325: 10 µA
PS350: 1 µA
Current Display Accuracy PS350: I Set Accuracy ±1 µA, typ ( ±2 µA, max)
PS325 or PS310: Accuracy ±10 µA, typ ( ±20 µA, max)
Stability 0.01% per hour, < 0.03% per 8 hours
Temperature Drift 50 ppm / °C, 0° to 50° C, typ
Protection Arc and short circuit protected; programmable voltage and
current limits and current trip.
(*) Regulation specifications apply for > 0.5% (full load) or 1.0% (no load) of full scale Voltage.
Below these values the unit may not regulate correctly.
