39
No.
REF. SRS part # VALUE DESCRIPTION
49. Z 0 0-00407-032 SOLDR SLV RG174 Termination
50. Z 0 7-00219-720 PS300-43 Fabricated Part
51. Z 0 7-00220-720 PS300-44 Fabricated Part
52. Z 0 9-00185-917 DANGER Product Labels
PS350 HV Board Parts List
No. REF. SRS part # VALUE DESCRIPTION
1. C 1 5-00175-539 .047U Capacitor, Metal Film, 4000 V
2. C 2 5-00175-539 .047U Capacitor, Metal Film, 4000 V
3. C 3 5-00175-539 .047U Capacitor, Metal Film, 4000 V
4. C 4 5-00175-539 .047U Capacitor, Metal Film, 4000 V
5. C 5 5-00333-533 .01U 6KV Capacitor, Metallized Polyester
6. C 6 5-00098-517 10U Capacitor, Tantalum, 35V, 20%, Rad
7. C 7 5-00098-517 10U Capacitor, Tantalum, 35V, 20%, Rad
8. C 8 5-00336-533 .04U 6KV Capacitor, Metallized Polyester
9. D 1 3-00285-301 CS57-04 Diode
10. D 2 3-00285-301 CS57-04 Diode
11. D 3 3-00285-301 CS57-04 Diode
12. D 4 3-00285-301 CS57-04 Diode
13. D 5 3-00221-301 1N4004 Diode
14. D 6 3-00221-301 1N4004 Diode
15. D 7 3-00667-301 SA12CA Diode
16. J 1 0-00138-050 9" #18 Wire #18 UL1007 Stripped 3/8x3/8 No Tin
17. J 2 0-00138-050 9" #18 Wire #18 UL1007 Stripped 3/8x3/8 No Tin
18. J 3 0-00280-050 9" #18 Wire #18 UL1007 Stripped 3/8x3/8 No Tin
19. J 6 0-00278-055 HV 4-1/2" Wire, Other
20. J 7 0-00278-055 HV 4-1/2" Wire, Other
21. J 8 0-00278-055 HV 4-1/2" Wire, Other
22. J 9 0-00277-053 4" #24 BLK Wire #24 UL1007 Strip 1/4x1/4 Tin
23. J 11 1-00082-100 1704-1 SHV Connector, Misc.
24. J 12 0-00278-055 HV 4-1/2" Wire, Other
25. J 13 0-00286-053 6" #24 GRN Wire #24 UL1007 Strip 1/4x1/4 Tin
26. J 14 0-00051-056 RG174 Cable, Coax & Misc.
27. J 15 0-00051-056 RG174 Cable, Coax & Misc.
28. PC1 7-00711-701 HV PS350 Printed Circuit Board
29. R 1 4-00451-448 10.0K Resistor, Metal Film, 1W, 1%,
30. R 2 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
31. R 3 4-01590-408 33.2K Resistor, Metal Film, 1/8W, 0.1%, 25ppm
32. R 4 4-00786-439 49.9 Resistor, Metal Film, 1/4W, 1%, 50ppm
33. R 5 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
34. R 6 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
35. R 7 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
36. R 8 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
37. R 9 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
38. R 10 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
39. R 11 4-01589-448 2.49M - 25PPM Resistor, Metal Film, 1W, 1%,
40. SW1 2-00030-210 3PDT-CUSTOM Switch, Rotary, PCB Mounted
41. T 1 6-00035-610 PS300-HV Transformer
