BR45 User Manual ◄ 19
BR45 T-HANDLE PARTS LIST
SEAL KIT PART NUMBER 04595
■ DENOTES PART IN SEAL KIT
* DENOTES PART OF BREAKER FOOT ASSEMBLY
ITEM
NO.
PART
NO.
QTY DESCRIPTION
1 01652 2 HOSE WHIP 12"
2 02494 2 HANDLE GRIP
3 02900 2 ROLL PIN 1/8 O.D. X .500 LG.
4 03972 1 COUPLER,3/8FEM.3/8NPT
FL.FACE SET 03971
5 03973 1 COUPLER,3/8MALE 3/8NPT
FL.FACE SET 03971
6 04058 1 COMPRESSION COIL SPRING
7 04077 1 VALVE SPOOL
8 04371 1 TRIGGER
9 04373 4 SIDE ROD
10 04374 4 HEX NUT
11 04378 1 PORTING BLOCK
12 04379 2 O-RING■
13 04381 2 BACK-UP RING■
14 04382 1 AUTOMATIC VALVE
15 04383 1 FLOW SLEEVE TUBE
16 04571 2 PUSH PIN
17 04605 4 PUSH PIN
18 07479 1 ACCUMULATOR DIAPHRAGM
19 07480 1 AUTOMATIC VALVE BODY
20 07481 1 PISTON
12833 1 PISTON (BR45550) (5-GPM
MODEL ONLY)
21 07483 1 HANDLE
22 07485 1 FLOW SLEEVE
23 ----- -- NO ITEM
24 07492 2 ROLL PIN
25 07493 1 O-RING PLUG MALE
26 04057 1 BUSHING
27 11588 1 ACCUMULATOR ON-OFF
VALVE BLOCK
28 20499 1 CHARGE VALVE
ITEM
NO.
PART
NO.
QTY DESCRIPTION
42 00293 1 O-RING■
43 01362 1 O-RING■
44 04056 1 ROD WIPER■
45 72919 2 FILLER (SNAP ON)
46 74832 2 STANLEY LOGO STICKER
(5.5” x 1.1” Black on Clear)
74770 2 STANLEY LOGO STICKER
(6.5” x 1.3” Yellow on Clear)
47 74664 1 NAME TAG BR45 (8-GPM)
T-HANDLE MODELS
74660 1 NAME TAG BR45 (5-GPM)
T-HANDLE MODELS
74669 1 NAME TAG BR45 (8-GPM)
T-HANDLE U/W MODEL
BUSHING ASSY 07699 (INCLUDES ITEMS 26,
42, 43, and 44)
PARTS LIST
