BR45 ANTI-VIBRATION HANDLE PARTS LIST
ITEM
NO.
PART
NO.
QTY DESCRIPTION
1 01652 2 HOSE WHIP 12"
56725 2 HOSE ASSY 18” BR45158
66727 2 HOSE ASSY BR45158BN
2 02494 2 HANDLE GRIP
3 02900 2 ROLL PIN
4 03972 1 COUPLER,3/8FEM. 3/8NPT
FL.FACE SET 03971
5 03973 1 COUPLER,3/8MALE 3/8NPT
FL.FACE SET 03971
6 04058 1 COMPRESSION COIL SPRING
7 04374 4 HEX NUT
8 04378 1 PORTING BLOCK
9 04379 2 O-RING*
10 04381 2 BACK-UP RING*
11 04382 1 AUTOMATIC VALVE
12 04383 1 FLOW SLEEVE TUBE
13 04571 2 PUSH PIN
14 04605 4 PUSH PIN
15 07479 1 ACCUMULATOR DIAPHRAGM
16 07480 1 AUTOMATIC VALVE BODY
17 07481 1 PISTON
12833 1 PISTON (BR4556801) (5-GPM
MODEL ONLY)
18 07485 1 FLOW SLEEVE
19 07493 1 PLUG - BR4514801, BR4516801,
BR4516807
20510 1 PLUG - BR45125S, BR45135S,
BR4513516
21 07624 1 ROLL PIN
22 07699 1 ◘ BUSHING ASSY.
23 10180 1 CAUTION N2 GAS STICKER
24 11207 1 CIRCUIT TYPE "D" STICKER
25 11588 1 ACCUMULATOR VALVE BLOCK
26 74832 2 STANLEY LOGO (5.5” x 1.1”
Black on Clear)
74770 STANLEY LOGO (6.5” x 1.3” Yel-
low on Clear)
27 20498 2 SPRING
20540 2
SPRING BR45158/BR45158BN
27A 20541 2 SPRING BR45158/BR45158BN
ITEM
NO.
PART
NO.
QTY DESCRIPTION
28 20499 1 CHARGE VALVE
29 20500 2 ROLL PIN
30 20505 1 HANDLE PIVOT BLOCK
31 20508 2 PIVOT SCREW
32 20511 1 LEVER
33 20515 1 VALVE SPOOL
34 20517 4 SIDE ROD
35 28322 1 STICKER "CE"
36 28369 1 HANDLE (GUARDED)
37 28409 1 COMPOSITE STICKER
38 28494 1 TOP PLATE
39 58526 1 CAST TRIGGER
40 58527 1 TRIGGER LOCK
41 58529 1 TRIGGER HANDLE (WITH TRIG-
GER LOCK
29045 1 TRIGGER HANDLE (NON-TRIG-
GER LOCK
42 58601 1 GUARANTEED SOUND POWER
LEVEL - 107dB
43 66828 1 TORSION SPRING
45 72919 2 FILLER (SNAP-ON)
46 74663 1 NAME TAG-BR45 8-GPM
74659 1 NAME TAG-BR45 5-GPM
47 00293 1 O-RING*
48 01362 1 O-RING*
49 04056 1 ROD WIPER*
52 04393 1 DETENT
SEAL KIT PART NUMBER 04595
■ DENOTES PART IN SEAL KIT
* DENOTES PART OF BREAKER FOOT ASSEMBLY
◘ BUSHING ASSY 07699 (INCLUDES ITEMS 22,
47, 48, and 49)
PARTS LIST
