Compulevel
TM
Measurement system • 10
Scale & Resolution
SCALE
You can choose any of six scales measuring elevation with
COMPULEVEL
TM
: 1) fractional inches, 2) decimal inches, 3) feet,
4) feet and inches, 5) centimetres, 6) meters.
To choose a measurement scale:
Press and hold the SCALE key for two seconds. Continue pressing the
SCALE key to sequence through all the scales. Release on the desired
scale. The current scale is indicated on the right side of the display
window.
RES
You can choose one of three level’s of resolution or measurement
precision in which to work with COMPULEVEL
TM
. Res 1, offers the highest
precision but requires longer for a reading to stabilise. Res 2, provides
intermediate precision and takes less time to obtain a stable reading.
Res 5, is best for rough measurements and provides the fastest readings.
To choose the preferred resolution:
Press and hold the RES key for two seconds to enter and continue
pressing to select the desired measurement resolution. The current
resolution level (ie. 1/8”, 1/4" or 1/2" when using inch scales) is shown
on the display window.
Release the RES key at the desired value.
Fractional inches
Decimal inches
Feet
Feet – Inches
Centimetr
es
Meters
EQUIVALENT
DISPLAY
READINGS
Right end of display
TYPICAL DISPLA
Y (Decimal inches display)
Longer
Shorter
Time for reading
to stabilise
Use for highest precision
Use for intermediate precision
Use for rough measurements
