EX5500 Controller Installation & Configuration Guide
27
EX5500 and Accessories Model Numbers
Product SKU Description
EX5500 Controller EX-5500 EX5500 Controller. Includes 48V DC input,
Ethernet and PoE interface
EX5500 Power
Supply
ADP-047 AC/DC adaptor 45W 48V/1.0A 90-264VAC.
PoE Injector ADP-030-U 110/220 VAC to 48 VDC PoE Single-Port
Injector
Exciter Detector Tool EXD-1000 Tool for visualizing the effective LF Exciter
transmission field. Analyzes the Exciter
coverage during deployment. Includes a PC
application and detector hardware that can
be connected via USB to a PC.
External LF Antenna ANT-4200 External LF Antenna Device. Powered
directly from the Exciter. Includes mounting
plate and a ceiling mount.
Exciter Mounting Clip EXAC-140 Heavy-duty Mounting Clip for Exciters.
Snaps easily onto the topside of the T-Grid
of a false ceiling with a standard 24" span
grid. Enables mounting the Exciter using
screws.
