EX5500 Controller Installation & Configuration Guide
28
EX5500 Specifications
Physical and Mechanical
Dimensions: 192mm X 242mm X 61mm (6.1in x 7.1in x 1.8in)
Weight: 450g (16oz)
Housing: Polycarbonate and ABS
Range
Adjustable from 0.5m (20 in) up to 6.5m (21.3ft) in intervals of 0.5m (20 in)
LF Channel
125kHz
Field intensity limits: 37.3dBµA/m at 10m (ETSI)
Propagation limits: 21.8dBµV/m at 300m (FCC)
Modulation: ASK
Network Interface
Ethernet (RJ-45)
Power
Input voltage: 12, 24-48VDC
PoE (802.3af) 48VDC
Maximum power consumption: 10W.
Maximum power consumption of External LF Antenna: 5W.
Environmental
Operating temperature: 0 to 50 °C (32°F to 122°F)
Humidity: 0 to 95%, non-condensing
