14
ENGLISH
1
⑩
Peel double-sided
tape on new scree
n
⑪⑫
Insert screen ca
ble into it connector an
d lock it
⑬⑭
Place screen ali
gning with the li
ne on the board.
⑮
Connect two boar
ds aligning 2 co
nnectors
⑯
Screw a cross-rece
ssed screw.
⑰
Peel the new scre
en film and connect
two
connectors.
⑱
Put the screen int
o housing.
⑲
Close the housing
with screws
⑩
⑪
⑫
⑰
⑯
⑮
⑭
⑬
⑱
⑲
13
15
