WARNING: Wear approved eye protection and approved dust mask when performing this procedure.
WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool.
These chemicals may weaken the materials used in these parts. Use a cloth dampened only with water
and mild soap. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid.
Cleaning the mandrel
• Remove the battery (K) from the tool.
• Loosen the nose housing nut (E). Remove the nose housing (D).
• Clean the mandrel (A) by using a metal brush to remove metal powder or debris.
• Lubricate by splaying a lubrication onto the thread and non-thread of the mandrel (A).
• Screw the nose housing nut (E) onto Mast housing (T).
Lubricate the spin pull head and spin pull head case (fig. 5)
• Remove the battery (K) from the tool. (fig.3).
• Loosen the nose housing nut (E). Remove the nose housing (D).
• Lubricate by spraying a lubrication between Spin pull head (R) and Spin pull head case (Q) every 1,000 nuts.
• Screw the nose housing nut (E) onto Mast housing (T).
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger from the AC outlet before cleaning.
Dirt and grease may be removed from the exterior of the charger using a cloth or soft non-metallic brush.
DO NOT use water or any cleaning solutions.
2.4
SPARE PARTS – TOOLS
For spare parts we refer you to the specific service manuals which you can find on our website at
http:// www.stanleyengineeredfastening.com/resource-center/document-library
2.5
RECHARGEABLE BATTERY PACK
This long-life battery pack must be recharged when it fails to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for our environment:
• Run the battery pack down completely, then remove it from the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a local recycling station. The collected battery packs
will be recycled or disposed of properly.
2.6
PROTECTING THE ENVIRONMENT
Separate collection. This product must not be disposed of with normal household waste.
Should you find one day that your STANLEY Engineered Fastening product needs replacement, or if it is
of no further use to you, do not dispose of it with household waste. Make this product available for
separate collection. Separate collection of used products and packaging allows materials to be recycled
and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the
demand for raw materials.
Local regulations may provide for separate collection of electrical products from the household, at
municipal waste sites or by the retailer when you purchase a new product.
You can check the location of your nearest authorised repair agent by contacting your local STANLEY
Engineered Fastening office at the address indicated in this manual. Alternatively, a list of authorised
STANLEY Engineered Fastening repair agents and full details of our after-sales service and contacts are
available on the Internet at: www.StanleyEngineeredFastening.com
